Introduction
SETI@home is a large volunteer distributed computing project where software running on participant systems is used to analyze space telescope radio data in order to identify signals or signs of intelligent life. SETI@home uses software known as BOINC which is available on many platforms including Linux.
BOINC has a graphical application but also works via the command line. This makes running SETI@home on a Droplet or another headless server very feasible. SETI@home requires very little disk space for usage — typically, 100MB of space is sufficient — but can utilize as much CPU as it's given.
Prerequisites
- An Ubuntu 14.04 or Debian 7 Droplet, any size.
- A sudo non-root user. You can follow the first four steps of this tutorial for setup on Ubuntu, and this tutorial for Debian.
Step One — Install boinc-client
SETI@home operates via the BOINC client which is available in the standard Debian and Ubuntu repositories.
sudo apt-get install boinc-client
Step Two — Connect to a SETI@home Account
With SETI@home, you'll earn SETI credit for work completed. To connect this host to a SETI@home account and receive credit, an account key is needed.
First, create a SETI@home account or log in to your existing SETI@home account. Once inside, click View next to Account keys.
You'll see your SETI@home account key on the top of the next page. Run the following command with your account key:
boinccmd --project_attach http://setiathome.berkeley.edu <^>account_key<^>
At this point, boinc will begin crunching away with default values.
For now, stop the boinc-client service so CPU usage preferences can be set.
sudo service boinc-client stop
Step Three — Configure Host CPU Usage Preferences
By default, the BOINC client will use 100% of available CPU. In this step, we will configure the host to use less CPU.
Note: In a cloud hosting environment, you are required to lower your CPU utilization from 100% to avoid excessive high usage, which might affect neighboring Droplets.
Local host preferences are set in the file /var/lib/boinc client/global_prefs_override.xml, which will be empty initially. An example file is given below for this guide, which is the recommended configuration for a Droplet.
Edit the file /var/lib/boinc-client/global_prefs_override.xml.
sudo nano /var/lib/boinc-client/global_prefs_override.xml
You will see an some existing text that looks like this:
<global_preferences>
</global_preferences>
Delete that, and paste in this example file.
<global_preferences>
<run_on_batteries>0</run_on_batteries>
<run_if_user_active>1</run_if_user_active>
<run_gpu_if_user_active>0</run_gpu_if_user_active>
<^><suspend_cpu_usage>50.000000</suspend_cpu_usage><^>
<start_hour>0.000000</start_hour>
<end_hour>0.000000</end_hour>
<net_start_hour>0.000000</net_start_hour>
<net_end_hour>0.000000</net_end_hour>
<leave_apps_in_memory>0</leave_apps_in_memory>
<confirm_before_connecting>1</confirm_before_connecting>
<hangup_if_dialed>0</hangup_if_dialed>
<dont_verify_images>0</dont_verify_images>
<work_buf_min_days>0.100000</work_buf_min_days>
<work_buf_additional_days>0.500000</work_buf_additional_days>
<max_ncpus_pct>100.000000</max_ncpus_pct>
<cpu_scheduling_period_minutes>60.000000</cpu_scheduling_period_minutes>
<disk_interval>60.000000</disk_interval>
<disk_max_used_gb>10.000000</disk_max_used_gb>
<disk_max_used_pct>90.000000</disk_max_used_pct>
<disk_min_free_gb>1.500000</disk_min_free_gb>
<vm_max_used_pct>75.000000</vm_max_used_pct>
<ram_max_used_busy_pct>50.000000</ram_max_used_busy_pct>
<ram_max_used_idle_pct>90.000000</ram_max_used_idle_pct>
<max_bytes_sec_up>0.000000</max_bytes_sec_up>
<max_bytes_sec_down>0.000000</max_bytes_sec_down>
<^><cpu_usage_limit>25.000000</cpu_usage_limit><^>
<daily_xfer_limit_mb>0.000000</daily_xfer_limit_mb>
<daily_xfer_period_days>0</daily_xfer_period_days>
</global_preferences>
Next we will inspect two settings in this example file concerning CPU, which are highlighted above.
The first preference is cpu_usage_limit, which is used to limit the amount of CPU used by SETI@home. The example file uses a setting of 25.000000, meaning CPU usage is limited to 25% max. 25.000000 is a good setting if your machine is dedicated for another task or service but contribution to SETI@home is still desired.
The second preference is suspend_cpu_usage which is used to temporarily suspend SETI@home from operation when CPU usage by other application reaches that level. In the example file, suspend_cpu_usage is set to 50.000000, or 50%.
You can read more about BOINC preferences on their wiki.
After saving and closing the file, start the boinc-client. This will allow SETI@home to start performing work.
sudo service boinc-client start
Step Four — Verify the Newly Added Host
After about five minutes, the new host should appear online. Connected computers can be viewed inside the SETI@home account page.
Step Five — Check the Status of Work Units
To view the status of work units or tasks, use the command:
boinccmd --get_simple_gui_info
Note that this displays your general SETI@home account information followed by current executing tasks on this specific host.
Below is example output for –get_simple_gui_info:
boinccmd --get_simple_gui_info
======== Projects ========
1) -----------
name: SETI@home
master URL: http://setiathome.berkeley.edu/
user_name: stmiller
team_name: SETI.USA
resource share: 100.000000
user_total_credit: 33159.675770
user_expavg_credit: 1409.252845
host_total_credit: 0.000000
host_expavg_credit: 0.000000
nrpc_failures: 0
master_fetch_failures: 0
master fetch pending: no
scheduler RPC pending: no
trickle upload pending: no
attached via Account Manager: no
ended: no
suspended via GUI: no
don't request more work: no
disk usage: 0.000000
last RPC: 1423684749.199424
project files downloaded: 0.000000
GUI URL:
name: Message boards
description: Correspond with other users on the SETI@home message boards
URL: http://setiathome.berkeley.edu/forum_index.php
GUI URL:
name: Help
description: Ask questions and report problems
URL: http://setiathome.berkeley.edu/forum_help_desk.php
GUI URL:
name: Your account
description: View your account information
URL: http://setiathome.berkeley.edu/home.php
GUI URL:
name: Your preferences
description: View and modify your computing preferences
URL: http://setiathome.berkeley.edu/prefs.php?subset=global
GUI URL:
name: Your results
description: View your last week (or more) of computational results and work
URL: http://setiathome.berkeley.edu/results.php?userid=9351194
GUI URL:
name: Your computers
description: View a listing of all the computers on which you are running SETI@Home
URL: http://setiathome.berkeley.edu/hosts_user.php?userid=9351194
GUI URL:
name: Your team
description: View information about your team: SETI.USA
URL: http://setiathome.berkeley.edu/team_display.php?teamid=115396
GUI URL:
name: Donate
description: Donate to SETI@home
URL: http://setiathome.berkeley.edu/sah_donate.php
======== Tasks ========
1) -----------
name: 25fe12ab.24545.17667.438086664204.12.226_0
WU name: 25fe12ab.24545.17667.438086664204.12.226
project URL: http://setiathome.berkeley.edu/
report deadline: Wed Mar 4 02:06:18 2015
ready to report: no
got server ack: no
final CPU time: 0.000000
state: downloaded
scheduler state: scheduled
exit_status: 0
signal: 0
suspended via GUI: no
active_task_state: EXECUTING
app version num: 701
checkpoint CPU time: 352.733700
current CPU time: 378.866400
fraction done: 0.088431
swap size: 110309376.000000
working set size: 40030207.999996
estimated CPU time remaining: 2505.901220
The status of SETI@home credit can also be viewed inside your account page under Computing and credit.
Conclusion
The SETI@home forum is the best place for news and questions about running SETI@home.
To join a team, view the team page!
