Step 1 - Spin up Ubuntu 12.10 x64 droplet and add SWAP memory
To add 2GB of SWAP memory on this droplet:
dd if=/dev/zero of=/swap bs=1024 count=2097152
mkswap /swap && chown root. /swap && chmod 0600 /swap && swapon /swap
echo /swap swap swap defaults 0 0 >> /etc/fstab
echo vm.swappiness = 0 >> /etc/sysctl.conf && sysctl -p
Step 2 - Install Packages on Monitoring Server
apt-get install -y nagios3 nagios-nrpe-plugin
usermod -a -G nagios www-data
chmod -R g+x /var/lib/nagios3/
sed -i 's/check_external_commands=0/check_external_commands=1/g' /etc/nagios3/nagios.cfg
You will be prompted for MySQL root password, we chose “PassWord”, you should change it to something stronger.
Step 3 - Set Password Protection
Set Nagios Admin Panel Password:
htpasswd -c /etc/nagios3/htpasswd.users nagiosadmin
service nagios3 restart && service apache2 restart
Make sure to keep this username as “nagiosadmin” – otherwise you would have to change /etc/nagios3/cgi.cfg and redefine authorized admin.
Now you can navigate over to your droplet’s Nagios panel at http://IP/nagios3 (http://198.211.117.129/nagios3/ for our example):
You will be prompted to enter your password, which you’ve specified in Step 3.
As you can see, we don’t have any hosts currently being monitored, so lets set that up next.
Step 4 - Install NRPE on Clients
Now we should add our hosts that will be monitored by Nagios. For example, we will setup monitoring for cloudads.tk (198.211.117.101), which runs Ubuntu 12.10 as well.
From public ports, we can monitor ping, any open ports such as webserver, e-mail server, etc.
For internal services that are listening on localhost, such as MySQL, memcached, system services, we will need to use NRPE.
Step 4 - Install NRPE on Client
apt-get install -y nagios-plugins nagios-nrpe-server
This next step is where you get to specify any manual commands that Monitoring server can send via NRPE to these client hosts.
Make sure to change allowed_hosts to your own values.
Edit <b>/etc/nagios/nrpe.cfg</b>
log_facility=daemon
pid_file=/var/run/nagios/nrpe.pid
server_port=5666
nrpe_user=nagios
nrpe_group=nagios
allowed_hosts=198.211.117.129
dont_blame_nrpe=1
debug=0
command_timeout=60
connection_timeout=300
include=/etc/nagios/nrpe_local.cfg
include_dir=/etc/nagios/nrpe.d/
command[check_users]=/usr/lib/nagios/plugins/check_users -w 5 -c 10
command[check_load]=/usr/lib/nagios/plugins/check_load -w 15,10,5 -c 30,25,20
command[check_hda1]=/usr/lib/nagios/plugins/check_disk -w 20% -c 10% -p /dev/vda
command[check_zombie_procs]=/usr/lib/nagios/plugins/check_procs -w 5 -c 10 -s Z
command[check_total_procs]=/usr/lib/nagios/plugins/check_procs -w 150 -c 200
Note:
In check_disk above, the partition being checked is /dev/vda – make sure your droplet has the same partition by running df -h /
You can also modify when to trigger warnings or critical alerts – above configuration sets Warning at 20% free disk space remaining, and Critical alert at 10% free space remaining.
We should also setup firewall rules to allow connections from our Monitoring server to those clients and drop everyone else:
iptables -N NRPE
iptables -I INPUT -s 0/0 -p tcp --dport 5666 -j NRPE
iptables -I NRPE -s 198.211.117.129 -j ACCEPT
iptables -A NRPE -s 0/0 -j DROP
/sbin/iptables-save
Now you can start NRPE on your client host:
service nagios-nrpe-server restart
Step 5 - Add Server Configurations on Monitoring Server
Back on our Monitoring server, we will have to create config files for each of our client servers:
All configs can be stored in /etc/nagios3/conf.d in individual .cfg files (for example: /etc/nagios3/conf.d/cloudads.tk.cfg)
Edit /etc/nagios3/conf.d/cloudads.tk.cfg and add the following lines:
define host {
use generic-host
host_name cloudads.tk
alias cloudads.tk
address 198.211.117.101
}
define service {
use generic-service
host_name cloudads.tk
service_description PING
check_command check_ping!100.0,20%!500.0,60%
}
define service {
use generic-service
host_name cloudads.tk
service_description SSH
check_command check_ssh
notifications_enabled 0
}
define service {
use generic-service
host_name cloudads.tk
service_description Current Load
check_command check_load!5.0!4.0!3.0!10.0!6.0!4.0
}
After you are done editing your config files, make sure to restart Nagios for changes to take effect:
service nagios3 restart
You can add more services to be monitored as desired, and even create your own Nagios plugins.
Step 6 - Monitor Hosts in Nagios
Navigate over to your Monitoring Server’s IP address http://IP/nagios3 and enter password set in Step 2.
Now you should be able to see all the hosts and services.
And you are all done!
