Introduction

WordPress has become one of the most popularly deployed and used web applications the world has ever seen. Thanks to years of constant development, it is now possible to create a nearly endless amount of different websites (or even web-applications) based on WordPress and its available plug-ins / extensions.

In this the cloud provider article, using the Docker Linux Container Engine, we are going learn how to dockerise (i.e. package and contain) WordPress applications on Ubuntu cloud servers and discover what probably is the most simple and secure way of deploying multiple WordPress sites on a single host.

Glossary

wordpress illustration for: Glossary

1. Docker In Brief

2. WordPress In Brief

3. Installing Docker on Ubuntu (latest)

4. Working With Docker

  1. Command Line Interface Usage And The Daemon
  1. Client Commands

5. Working With Dockerfiles

  1. What Are Dockerfiles?
  1. Dockerfile Commands Overview

6. Creating WordPress Containers

  1. Pulling The Image
  1. Creating A Publicly Accessible WordPress Container
  1. Creating A Locally Accessible WordPress Container
  1. Limiting The Memory Usage For Containers

Docker In Brief

—

The Docker project offers higher-level tools, working together, which are built on top of some Linux kernel features with the goal of helping developers and system administrators port applications – with all of their dependencies conjointly – and get them running across systems and machines *headache free*.

Docker achieves this by creating safe, LXC (Linux Containers) based environments for applications called "containers" which are created using images. These bases for containers can be built either by executing commands manually by logging inside like a virtual-machine, or by automating the process through Dockerfiles.

Note: To learn more about Docker and its parts (i.e. the docker daemon, CLI, images, etc.), check out our introductory article to the project: Docker Explained: Getting Started.

WordPress In Brief

—

WordPress was initially created as an easy to install and use self-publication platform (i.e. a Blogging engine). It has become extremely popular over the years, which lead to development of many 3rd party plugins, turning the tool into a full CMS (Content Management System). Based on WordPress, a lot of different types of web-sites and web-applications can be created with simplicity and deployed with ease.

WordPress is an open-source platform that is developed using the PHP programming language, which surely helped it on its way to success. PHP is currently one of the most common web-site and web-application creation languages and the choice of many companies (including Facebook).

WordPress sites rely on MySQL relational-database to keep their data and there are multiple ways to power a WordPress site given the multiple choices available to run PHP and MySQL together.

In this article, we will go with a tried-and-tested method to create WordPress installed Docker images, which will enable you to run yet-another WordPress site on any VPS, with a single command by using Docker.

Installing Docker on Ubuntu (latest)

—

Update your droplet

—

sudo apt-get update

sudo apt-get -y upgrade

Make Sure aufs Support Is Available

—

sudo apt-get install linux-image-extra-uname -r

Add The Docker Repository Key To apt-key For Package Verification

—

sudo apt-key adv –keyserver keyserver.ubuntu.com –recv-keys 36A1D7869245C8950F966E92D8576A8BA88D21E9

Add The Docker Repository To Sources

—

sudo sh -c "echo deb http://get.docker.io/ubuntu docker main\

> /etc/apt/sources.list.d/docker.list"

Update The Repository

—

sudo apt-get update

Download And Install Docker

—

sudo apt-get install lxc-docker git

Ubuntu's default firewall (UFW: Uncomplicated Firewall) denies all forwarding traffic by default, which is needed by docker.

Enable Forwarding With UFW

—

Edit UFW configuration using the nano text editor.

sudo nano /etc/default/ufw

Scroll down and find the line beginning with *DEFAULT_FORWARD_POLICY*.

Replace:

DEFAULT_FORWARD_POLICY="DROP"

with:

DEFAULT_FORWARD_POLICY="ACCEPT"

Press CTRL+X and approve with Y to save and close.

Reload The UFW

—

sudo ufw reload

Allowing Remote Connections

—

If you are planning on using the docker daemon remotely, then you will need to allow the default Docker port 4243.

sudo ufw allow 4243/tcp

Working With Docker

—

Before we begin working with docker, let's quickly go over its available commands to refresh our memory from our first _Getting Started_ article.

Command Line Interface Usage And The Daemon

—

Upon installation, the docker daemon should be running in the background, ready to accept commands sent by the docker client. For certain situations where it might be necessary to manually run Docker, use the following.

Running the docker daemon:

sudo docker -d &

Client Usage:

sudo docker [option] [command] [arguments]

Note: Docker needs sudo privileges in order to work as it uses sockets owned by root.

Client Commands

—

You can get a full list of all available commands by simply calling the client:

docker

Here is a list of all available commands as of version 0.8.0:

Commands:

attach Attach to a running container

build Build a container from a Dockerfile

commit Create a new image from a container's changes

cp Copy files/folders from the containers filesystem to the host path

diff Inspect changes on a container's filesystem

events Get real time events from the server

export Stream the contents of a container as a tar archive

history Show the history of an image

images List images

import Create a new filesystem image from the contents of a tarball

info Display system-wide information

insert Insert a file in an image

inspect Return low-level information on a container

kill Kill a running container

load Load an image from a tar archive

login Register or Login to the docker registry server

logs Fetch the logs of a container

port Lookup the public-facing port which is NAT-ed to PRIVATE_PORT

ps List containers

pull Pull an image or a repository from the docker registry server

push Push an image or a repository to the docker registry server

restart Restart a running container

rm Remove one or more containers

rmi Remove one or more images

run Run a command in a new container

save Save an image to a tar archive

search Search for an image in the docker index

start Start a stopped container

stop Stop a running container

tag Tag an image into a repository

top Lookup the running processes of a container

version Show the docker version information

wait Block until a container stops, then print its exit code

Working With Dockerfiles

—

What Are Dockerfiles?

—

Dockerfiles are scripts containing *commands* declared successively which are to be executed, in the order given, by Docker to automatically create a new image.

These files always begin with the definition of a base image with the FROM instruction. From there on, the *build process* starts and each following action forms the final image with commits (i.e. saving the image state).

Dockerfiles can be used with the build command:

sudo docker build -t wordpress_img .

Note: To learn more about Dockerfiles, check out the article: Docker Explained: Using Dockerfiles to Automate Building of Images.

Dockerfile Commands Overview

—

Dockerfiles work by receiving the below instructions:

  • ADD: Copy a file from the host into the container
  • CMD: Set default commands to be executed, or passed to the ENTRYPOINT
  • ENTRYPOINT: Set the default entrypoint application inside the container
  • ENV: Set environment variable (e.g. key = value)
  • EXPOSE: Expose a port to outside
  • FROM: Set the base image to use
  • MAINTAINER: Set the author / owner data of the Dockerfile
  • RUN: Run a command and commit the ending result (container) image
  • USER: Set the user to run the containers from the image
  • VOLUME: Mount a directory from the host to the container
  • WORKDIR: Set the directory for the directives of CMD to be executed

Creating WordPress Containers

—

Pulling The Image

—

For our tutorial, we will be using an out-of-the-box WordPress image called tutum/wordpress. This wordpress image is created using Tutum's WordPress Image: In order to create containers from this image, we need to pull (download) it first.

Let's pull the image:

docker pull tutum/wordpress

This command will download the underlying base images with all modified layers.

Once the image is ready, by issuing a single command we can create dockerised WordPress instances.

Creating A Publicly Accessible WordPress Container

—

Run the following command to create a container that is reachable from the outside on a port you specify (e.g. 80):

docker run -p 80:80 tutum/wordpress

The above command will create a WordPress instance that will accept connections from the outside on the default HTTP port 80.

Creating A Locally Accessible WordPress Container

—

Sometimes it might suit you the best to have containers reachable only locally. This can be useful if you decide to set up a load-balancer or another reverse-proxy to distribute connections across many WordPress instances.

Run the following command to create a locally accessible container.

docker run -p 127.0.0.1::80 tutum/wordpress

Once you execute the above command, Docker will create a container, provide you its ID and then dynamically allocate a port. You can figure out which port the container is using with the port command.

docker port 9af15d73fdf8a997 80

In this case, the output means that the container is accessible only on the localhost on port 49156. You can use the address, provided in full, to redirect connections from a reverse-proxy.

If you would like to specify a port, just place it in-between the IP address and the private port used by the web server inside (e.g. 80):

docker run -p 127.0.0.1:8081:80 tutum/wordpress

This way, you will have a WordPress instance that is locally accessible at port 8081.

Note: In order to run your container in the background, you also need to add the -d flag after the run command:

docker run -d ..

Otherwise, you will be connected *to* the container where you will see the output from all the applications running.

In order to leave the container, as shown in the introduction article, you need to use the escape sequence CTRL+P immediately followed by CTRL+Q.

Using the docker ps command, you can get the list of running containers to find your newly instantiated one's ID.

Note: Using the -name [name] arguments, you can *tag* a container with a name which should free you from dealing with complex container IDs:

docker run -d -name new_container_1 ..

Limiting The Memory Usage For Containers

—

In order to limit the amount of memory a docker container process can use, simply set the -m [memory amount] flag with the limit.

To run a container with memory limited to 256 MBs:

docker run -m 64m -d -p 8082:80 tutum/wordpress

To confirm the memory limit, you can *inspect* the container:

docker inspect 9a7562a361122706 | grep Memory

Note: The command above will grab the memory related information from the inspection output. To see all the relevant information regarding your container, opt for sudo docker inspect [container ID]. Also, please note that your Linux kernel must support swap limit capabilities for actual limitation to work.

For the full set of instructions to install and use docker, check out the docker documentation at docker.io.
