This article supplements a webinar series on deploying and managing containerized workloads in the cloud. The series covers the essentials of containers, including managing container lifecycles, deploying multi-container applications, scaling workloads, and working with Kubernetes. It also highlights best practices for running stateful applications.
This tutorial includes the concepts and commands in the fifth session of the series, Deploying and Scaling Microservices in Kubernetes.
[youtube LS57ul_cTsA 480 854]
Introduction
Kubernetes is an open-source container orchestration tool for managing containerized applications. In the previous tutorial in this series, A Closer Look at Kubernetes you learned the building blocks of Kubernetes.
In this tutorial, you will apply the concepts from the previous tutorials to build, deploy, and manage an end-to-end microservices application in Kubernetes. The sample web application you'll use in this tutorial is a "todo list" application written in Node.js that uses MongoDB as a database. This is the same application we used in the tutorial Building Containerized Applications.
You'll build a container image for this app from a Dockerfile, push the image to Docker Hub, and then deploy it to your cluster. Then you'll scale the app to meet increased demand.
Prerequisites
To complete this tutorial, you'll need:
- A Kubernetes cluster, which you can configure in the third part of this tutorial series, Getting Started with Kubernetes.
- An active Docker Hub account to store the image.
- Git installed on your local machine. You can follow the tutorial Contributing to Open Source: Getting Started with Git to install and set up Git on your computer.
Step 1 – Build an Image with Dockerfile
We will begin by containerizing the web application by packaging it into a Docker image.
Start by changing to your home directory, then use Git to clone this tutorial's sample web application from its official repository on GitHub.
cd ~
git clone https://github.com/janakiramm/todo-app.git
Build the container image from the Dockerfile. Use the -t switch to tag the image with the registry username, image name, and an optional tag.
docker build -t sammy/todo .
The output confirms that the image was successfully built and tagged appropriately.
[secondary_label Output]
Sending build context to Docker daemon 8.238MB
Step 1/7 : FROM node:slim
---> 286b1e0e7d3f
Step 2/7 : LABEL maintainer = "jani@janakiram.com"
---> Using cache
---> ab0e049cf6f8
Step 3/7 : RUN mkdir -p /usr/src/app
---> Using cache
---> 897176832f4d
Step 4/7 : WORKDIR /usr/src/app
---> Using cache
---> 3670f0147bed
Step 5/7 : COPY ./app/ ./
---> Using cache
---> e28c7c1be1a0
Step 6/7 : RUN npm install
---> Using cache
---> 7ce5b1d0aa65
Step 7/7 : CMD node app.js
---> Using cache
---> 2cef2238de24
Successfully built 2cef2238de24
Successfully tagged sammy/todo-app:latest
Verify that the image is created by running the docker images command.
docker images
You can see the size of the image along with the time since it was created.
[secondary_label Output]
REPOSITORY TAG IMAGE ID CREATED SIZE
sammy/todo-app latest 81f5f605d1ca 9 minutes ago 236MB
Next, push your image to the public registry on Docker Hub. To do this, log in to your Docker Hub account:
docker login
Once you provide your credentials, tag your image using your Docker Hub username:
docker tag <^>your_docker_hub_username<^>/todo-app
Then push your image to Docker Hub:
docker push
You can verify that the new image is available by searching Docker Hub in your web browser.
With the Docker image pushed to the registry, let's package the application for Kubernetes.
Step 2 – Deploy MongoDB Pod in Kubernetes
The application uses MongoDB to store to-do lists created through the web application. To run MongoDB in Kubernetes, we need to package it as a Pod. When we launch this Pod, it will run a single instance of MongoDB.
Create a new YAML file called db-pod.yaml:
nano db-pod.yaml
Add the following code which defines a Pod with one container based on MongoDB. We expose port 27017, the standard port used by MongoDB. Notice that the definition contains the labels name and app. We'll use those labels to identify and configure specific Pods.
[label db-pod.yaml]
apiVersion: v1
kind: Pod
metadata:
name: db
labels:
name: mongo
app: todoapp
spec:
containers:
- image: mongo
name: mongo
ports:
- name: mongo
containerPort: 27017
volumeMounts:
- name: mongo-storage
mountPath: /data/db
volumes:
- name: mongo-storage
hostPath:
path: /data/db
The data is stored in the volume called mongo-storage which is mapped to the /data/db location of the node. For more information on Volumes, refer to the official Kubernetes volumes documentation.
Run the following command to create a Pod.
kubectl create -f db-pod.yml
You'll see this output:
[secondary_label Output]
pod "db" created
Now verify the creation of the Pod.
kubectl get pods
The output shows the Pod and indicates that it is running:
[secondary_label Output]
NAME READY STATUS RESTARTS AGE
db 1/1 <^>Running<^> 0 2m
Let's make this Pod accessible to the internal consumers of the cluster.
Create a new file called db-service.yaml that contains this code which defines the Service for MongoDB:
[label db-service.yaml]
apiVersion: v1
kind: Service
metadata:
name: db
labels:
name: mongo
app: <^>todoapp<^>
spec:
selector:
name: mongo
type: ClusterIP
ports:
- name: db
port: 27017
targetPort: 27017
The Service discovers all the Pods in the same Namespace that match the Label with name: db. The selector section of the YAML file explicitly defines this association.
We specify that the Service is visible within the cluster through the declaration type: ClusterIP .
Save the file and exit the editor. Then use kubectl to submit it to the cluster.
kubectl create -f db-service.yml
You’ll see this output indicating the Service was created successfully:
[secondary_label Output]
service "db" created
Let’s get the port on which the Pod is available.
kubectl get services
You'll see this output:
[secondary_label Output]
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
db ClusterIP 10.109.114.243 <none> <^>27017/TCP<^> 14s
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 47m
From this output, you can see that the Service is available on port 27017. The web application can reach MongoDB through this service. When it uses the hostname db, the DNS service running within Kubernetes will resolve the address to the ClusterIP associated with the Service. This mechanism allows Pods to discover and communicate with each other.
With the database Pod and Service in place, let's create a Pod for the web application.
Step 3 – Deploy the Node.JS Web App as a Pod
Let's package the Docker image you created in the first step of this tutorial as a Pod and deploy it to the cluster. This will act as the front-end web application layer accessible to end users.
Create a new YAML file called web-pod.yaml:
nano web-pod.yaml
Add the following code which defines a Pod with one container based on the sammy/todo-app Docker image. It is exposed on port 3000 over the TCP protocol.
[label web-pod.yaml]
apiVersion: v1
kind: Pod
metadata:
name: web
labels:
name: web
app: <^>todoapp<^>
spec:
containers:
- image: sammy/todo-app
name: myweb
ports:
- containerPort: 3000
Notice that the definition contains the labels name and app. A Service will use these labels to route inbound traffic to the appropriate ports.
Run the following command to create the Pod:
kubectl create -f web-pod.yaml
[secondary_label Output]
pod "web" created
Let’s verify the creation of the Pod:
kubectl get pods
[secondary_label Output]
NAME READY STATUS RESTARTS AGE
<^>db<^> 1/1 Running 0 8m
<^>web<^> 1/1 Running 0 9s
Notice that we have both the MongoDB database and web app running as Pods.
Now we will make the web Pod accessible to the public Internet.
Services expose a set of Pods either internally or externally. Let’s define a Service that makes the web Pod publicly available. We’ll expose it through a NodePort, a scheme that makes the Pod accessible through an arbitrary port opened on each Node of the cluster.
Create a new file called web-service.yaml that contains this code which defines the Service for the app:
apiVersion: v1
kind: Service
metadata:
name: web
labels:
name: web
app: <^>todoapp<^>
spec:
selector:
name: web
type: NodePort
ports:
- name: http
port: 3000
targetPort: 3000
protocol: TCP
The Service discovers all the Pods in the same Namespace that match the Label with the name web. The selector section of the YAML file explicitly defines this association.
We specify that the Service is of type NodePort through the type: NodePort declaration.
Use kubectl to submit this to the cluster.
kubectl create -f web-service.yml
You’ll see this output indicating the Service was created successfully:
[secondary_label Output]
service "web" created
Let’s get the port on which the Pod is available.
kubectl get services
[secondary_label Output]
NAME TYPE CLUSTER-IP EXTERNAL-IP PORT(S) AGE
db ClusterIP 10.109.114.243 <none> 27017/TCP 12m
kubernetes ClusterIP 10.96.0.1 <none> 443/TCP 59m
web NodePort 10.107.206.92 <none> 3000:<^>30770/TCP<^> 12s
From this output, we see that the Service is available on port 30770. Let’s try to connect to one of the Worker Nodes.
Obtain the public IP address for one of the Worker Nodes associated with your Kubernetes Cluster by using the the cloud provider console.
Once you've obtained the IP address, use the curl command to make an HTTP request to one of the nodes on port 30770:
curl http://<^>your_worker_ip_address<^>:30770
You'll see output similar to this:
[secondary_label Output]
<!DOCTYPE html>
<html>
<head>
<title>Containers Todo Example</title>
<link rel='stylesheet' href='/stylesheets/screen.css' />
<!--[if lt IE 9]>
<script src="https://html5shiv.googlecode.com/svn/trunk/html5.js"></script>
<![endif]-->
</head>
<body>
<div id="layout">
<h1 id="page-title">Containers Todo Example</h1>
<div id="list">
<form action="/create" method="post" accept-charset="utf-8">
<div class="item-new">
<input class="input" type="text" name="content" />
</div>
</form>
</div>
<div id="layout-footer"></div>
</div>
<script src="/javascripts/ga.js"></script>
</body>
</html>
You’ve defined the web Pod and a Service. Now let’s look at scaling it with Replica Sets.
Step 5 – Scaling the web application
A Replica Set ensures that a minimum number of Pods are running in the cluster at all times. When a Pod is packaged as a Replica Set, Kubernetes will always run the minimum number of Pods defined in the specification.
Let’s delete the current Pod and recreate two Pods through the Replica Set. If we leave the Pod running it will not be a part of the Replica Set. Thus, it's a good idea to launch Pods through a Replica Set, even when the count is just one.
First, delete the existing Pod.
kubectl delete pod web
[secondary_label Output]
pod "web" deleted
Now create a new Replica Set declaration. The definition of the Replica Set is identical to a Pod. The key difference is that it contains the replica element which defines the number of Pods that need to run. Like a Pod, it also contains Labels as metadata that help in Service discovery.
Create the file web-rs.yaml and add this code to the file:
apiVersion: extensions/v1beta1
kind: ReplicaSet
metadata:
name: web
labels:
name: web
app: todoapp
spec:
replicas: 2
template:
metadata:
labels:
name: web
spec:
containers:
- name: web
image: sammy/todo-app
ports:
- containerPort: 3000
Save and close the file.
Now create the Replica Set:
kubectl create -f web-rs.yaml
[secondary_label Output]
replicaset "web" created
Then check the number of Pods:
kubectl get pods
[secondary_label Output]
NAME READY STATUS RESTARTS AGE
db 1/1 Running 0 18m
web-n5l5h 1/1 Running 0 25s
web-wh6nf 1/1 Running 0 25s
When we access the Service through the NodePort, the request will be sent to one of the Pods managed by the Replica Set.
Let’s test the functionality of a Replica Set by deleting one of the Pods and seeing what happens:
kubectl delete pod web-wh6nf
[secondary_label Output]
pod "web-wh6nf" deleted
Look at the Pods again:
kubectl get pods
[secondary_label Output]
NAME READY STATUS RESTARTS AGE
db 1/1 Running 0 19m
web-n5l5h 1/1 Running 0 1m
web-wh6nf 1/1 Terminating 0 1m
web-ws59m 0/1 ContainerCreating 0 2s
As soon as the Pod is deleted, Kubernetes has created another one to ensure the desired count is maintained.
We can scale the Replica Set to run additional web Pods.
Run the following command to scale the web application to 10 Pods.
kubectl scale rs/web --replicas=<^>10<^>
[secondary_label Output]
replicaset "web" scaled
Check the Pod count:
kubectl get pods
You'll see this output:
[secondary_label Output]
NAME READY STATUS RESTARTS AGE
db 1/1 Running 0 22m
web-4nh4g 1/1 Running 0 21s
web-7vbb5 1/1 Running 0 21s
web-8zd55 1/1 Running 0 21s
web-f8hvq 0/1 ContainerCreating 0 21s
web-ffrt6 1/1 Running 0 21s
web-k6zv7 0/1 ContainerCreating 0 21s
web-n5l5h 1/1 Running 0 3m
web-qmdxn 1/1 Running 0 21s
web-vc45m 1/1 Running 0 21s
web-ws59m 1/1 Running 0 2m
Kubernetes has initiated the process of scaling the web Pod. When the request comes to the Service via the NodePort, it gets routed to one of the Pods in the Replica Set.
When the traffic and load subsides, we can revert to the original configuration of two Pods.
kubectl scale rs/web --replicas=<^>2<^>
[secondary_label Output]
replicaset "web" scaled
This command terminates all the Pods except two.
kubectl get pods
[secondary_label Output]
NAME READY STATUS RESTARTS AGE
db 1/1 Running 0 24m
web-4nh4g 1/1 Terminating 0 2m
web-7vbb5 1/1 Terminating 0 2m
web-8zd55 1/1 Terminating 0 2m
web-f8hvq 1/1 Terminating 0 2m
web-ffrt6 1/1 Terminating 0 2m
web-k6zv7 1/1 Terminating 0 2m
web-n5l5h 1/1 Running 0 5m
web-qmdxn 1/1 Terminating 0 2m
web-vc45m 1/1 Terminating 0 2m
web-ws59m 1/1 Running 0 4m
To verify the availability of the Replica Set, try deleting one of the Pods and check the count.
kubectl delete pod web-ws59m
[secondary_label Output]
pod "web-ws59m" deleted
kubectl get pods
[secondary_label Output]
NAME READY STATUS RESTARTS AGE
db 1/1 Running 0 25m
web-n5l5h 1/1 Running 0 7m
web-ws59m 1/1 Terminating 0 5m
web-z6r2g 0/1 ContainerCreating 0 5s
As soon as the Pod count changes, Kubernetes adjusts it to match the count defined in the YAML file. When one of the web Pods in the Replica Set is deleted, another Pod is immediately created to maintain the desired count. This ensures high availability of the application by ensuring that the minimum number of Pods are running all the time.
You can delete all the objects created during this tutorial with the following command:
kubectl delete -f db-pod.yaml -f db-service.yaml -f web-rs.yaml -f web-service.yaml
[secondary_label Output]
pod "db" deleted
service "db" deleted
replicaset "web" deleted
service "web" deleted
Conclusion
In this tutorial, you applied all the concepts covered in the series to package, deploy, and scale a microservices applications.
In the next part of this series, you will learn how to make MongoDB highly available by running it as a StatefulSet.
