Status: Deprecated

powerdns illustration for: Status: Deprecated

This article covers a version of CentOS that is no longer supported. If you are currently operating a server running CentOS 6, we highly recommend upgrading or migrating to a supported version of CentOS.

Reason: CentOS 6 reached end of life (EOL) on November 30th, 2020 and no longer receives security patches or updates. For this reason, this guide is no longer maintained.

Step 1 - Install REMI and EPEL Repositories and Packages


					rpm -ivh http://dl.fedoraproject.org/pub/epel/6/x86_64/epel-release-6-8.noarch.rpm

rpm -ivh http://rpms.famillecollet.com/enterprise/remi-release-6.rpm

yum -y install php php-mcrypt php-pdo php-mysql pdns pdns-backend-mysql mysql-server httpd

Step 2 - Create a Database and Username


					service mysqld start

service httpd start

mysqladmin create powerdns

Make sure to select your own password below:


					mysql -Bse "create user 'powerdns'@'localhost' identified by 'password'"

mysql -Bse "grant all privileges on powerdns.* to 'powerdns'@'localhost'"

Step 3 - Create PowerDNS databases and tables:

Start mysql console with “mysql”


					mysql&gt; use powerdns;



					CREATE TABLE domains (

id INT auto_increment,

name VARCHAR(255) NOT NULL,

master VARCHAR(128) DEFAULT NULL,

last_check INT DEFAULT NULL,

type VARCHAR(6) NOT NULL,

notified_serial INT DEFAULT NULL,

account VARCHAR(40) DEFAULT NULL,

primary key (id)

);

CREATE UNIQUE INDEX name_index ON domains(name);

CREATE TABLE records (

id INT auto_increment,

domain_id INT DEFAULT NULL,

name VARCHAR(255) DEFAULT NULL,

type VARCHAR(6) DEFAULT NULL,

content VARCHAR(255) DEFAULT NULL,

ttl INT DEFAULT NULL,

prio INT DEFAULT NULL,

change_date INT DEFAULT NULL,

primary key(id)

);

CREATE INDEX rec_name_index ON records(name);

CREATE INDEX nametype_index ON records(name,type);

CREATE INDEX domain_id ON records(domain_id);

CREATE TABLE supermasters (

ip VARCHAR(25) NOT NULL,

nameserver VARCHAR(255) NOT NULL,

account VARCHAR(40) DEFAULT NULL

);

Exit mysql console by typing “exit”:


					mysql&gt; exit

<h3>Step 4 – Install PowerAdmin</h2>

Login as root and run:


					cd /root

wget https://github.com/downloads/poweradmin/poweradmin/poweradmin-2.1.6.tgz

tar xvfz poweradmin-2.1.6.tgz

cd poweradmin-2.1.6/inc

mv config-me.inc.php config.inc.php

Edit config.inc.php and make sure to change password you’ve specified in Step 2:


					nano config.inc.php

Modify db_pass and session_key to your own values:


					$db_host                = 'localhost';

$db_port                = '3306';

$db_user                = 'powerdns';

$db_pass                = 'password';

$db_name                = 'powerdns';

$db_type                = 'mysql';

$session_key            = 'session_key';

Move PowerAdmin folder to Apache’s DocumentRoot. We can use this droplet’s IP address to manage our DNS settings


					mv /root/poweradmin-2.1.6/* /var/www/html/

service httpd restart

Edit /etc/pdns/pdns.conf and add the following lines, make sure to modify gmysql-password to MySQL password you’ve selected in Step 2:


					launch=gmysql

gmysql-host=localhost

gmysql-user=powerdns

gmysql-password=password

gmysql-dbname=powerdns

Restart Power DNS daemon:


					service pdns restart

Step 5 - Create PowerAdmin Account

Proceed to installing PowerAdmin from webserver. Navigate over to your droplet's IP /install folder (in our case http://198.211.110.153/install/ ).

<img src="images/how-to-install-powerdns-on-centos-6-3-x64-section-1.png; width="680">

Create a Poweradmin admin account:

<img src="images/how-to-install-powerdns-on-centos-6-3-x64-section-1.png; width="680">

Next step is optional:

<img src="images/how-to-install-powerdns-on-centos-6-3-x64-section-1.png; width="680">

Finish the installation process, and after you get to Step 7, remove /var/www/html/install folder:


					rm -rf /var/www/html/install

Now you can navigate to your droplet’s IP ( http://198.211.110.153/ in our case), and login as admin with password you’ve specified in Step 5.

Now you can create your own DNS zone records:

<img src="images/how-to-install-powerdns-on-centos-6-3-x64-section-1.png; width="680">

You can verify that your new PowerDNS server is working by running dig against it:


					dig @198.211.110.153 domain.com

;; ANSWER SECTION:

domain.com.             86400   IN      A       127.0.0.1

And you are all done!
