Introduction

This tutorial will teach you to:

  • Deploy and configure a cloud servers to act as an Egress gateway for your DOKS cluster, via Crossplane.
  • Deploy the Static Routes Operator, and configure static routes on your DOKS cluster worker nodes to egress workloads traffic to all public IP ranges (some restrictions apply), or to specific destinations only.

What is an Egress gateway, and why is it important?

No matter where your resources (DOKS, Droplets, etc.) are deployed and running, they live in a private network or VPC. The private network can be at home behind your ISP router, in a private data center (on-premise), or in a cloud-based environment. The main role of a VPC is to isolate different networks across different regions. Different VPCs can talk to each other via gateways (which are routers).

Next, you need to get familiar with some terminology associated with inbound and outbound traffic, explained below:

  • Ingress deals with inbound traffic entering your VPC.
  • Egress deals with outbound traffic exiting your VPC.

When using Kubernetes, you manage incoming traffic via an Ingress resource. But, for outgoing traffic there is no Egress resource in the Kubernetes spec. It can be implemented in the CNI layer. For example Cilium, which is used by DOKS, has an Egress Gateway spec. But, in the case of Kubernetes, it's not quite stable or production-ready yet.

There are three key aspects related to egress functionality:

  1. Restricting egress traffic (not covered in this guide).
  2. NAT outgoing.
  3. Egress gateways.

Restricting egress (or outgoing) traffic is not covered in this blueprint but, in essence, is a way of restricting outbound traffic for cluster Pods. It can be achieved via network policies or firewalls. A firewall is the most common use case, where you allow connections only to a particular external IP address range or to external services. Firewalls cannot distinguish between individual Pods, so the rules apply equally.

To build an egress gateway, you need NAT functionality, implemented using a NAT gateway. In essence, a NAT gateway sits at the edge of your private network (or VPC), through which outbound (or egress) traffic flows to the public internet. The main role of NAT, which stands for Network Address Translation, is to make network packets routable outside your private network (or VPC). The process also needs to work in reverse order, meaning incoming response packets need to be routed back to the originating private IP inside your VPC.

Your VPC uses a specific IP range (e.g., 10.116.0.0/20), which needs to be translated to a public IP address so that packets can flow to a specific destination outside your private network (i.e., Internet). When a response packet comes in, the NAT layer must translate the public IP address from the packet header to the private network address of the host where the traffic originated. This is what NAT is for.

A dedicated machine configured for this purpose is called a NAT gateway. When attached to a DOKS cluster, it can route all (or specific destinations only) traffic via a single routable public IP. Hence, we can call it an Egress Gateway in this context.

Moving further with a practical example, suppose you need to use an external service such as a database. The database is usually in another data center outside your private network (or VPC). The database administrator configured the firewall so that only specific public IPs can connect. You already egress from your DOKS cluster nodes because they are connected directly to the Internet, but it's not practical because nodes are volatile, hence the public IPs will change.

Consequently, on the other end (i.e. database service), you need to change network ACLs again to allow the new public IPs – not good. An egress gateway ensures that all traffic from your application Pods inside the Kubernetes cluster is seen as coming from a single public IP. That is, the public IP of the egress gateway. You can go even further and use a reserved IP for the egress gateway, so it will never change.

Below is a diagram showing the main setup for egressing DOKS cluster traffic to an external service (i.e., database):

Table of Contents

static illustration for: Table of Contents
  • [Overview](#overview)
  • [Prerequisites](#prerequisites)
  • [Step 1 – Introducing Crossplane](#step-1—introducing-crossplane)
  • [Step 2 – Installing Crossplane](#step-2—installing-crossplane)
  • [Step 3 – Introducing Static Routes Operator](#step-3—introducing-static-routes-operator)
  • [Step 4 – Installing Static Routes Operator](#step-4—installing-static-routes-operator)
  • [Step 5 – Creating an Egress Gateway using Crossplane](#step-5—creating-an-egress-gateway-using-crossplane)
  • [Installing the the cloud provider Provider Package](#installing-the-the cloud provider-provider-package)
  • [Configuring the the cloud provider Provider](#configuring-the-the cloud provider-provider)
  • [Provisioning the Egress Gateway Droplet Resource](#provisioning-the-egress-gateway-droplet-resource)
  • [Step 6 – Configuring Static Routes for your Egress Gateway](#step-6—configuring-static-routes-for-your-egress-gateway)
  • [Step 7 – Testing the DOKS Cluster Egress Setup](#step-7—testing-the-doks-cluster-egress-setup)
  • [Step 8 – Configuring the Static Routes Controller to Egress All Cluster Traffic](#step-8—configuring-the-static-routes-controller-to-egress-all-cluster-traffic)
  • [Cleaning Up](#cleaning-up)
  • [Uninstalling the Static Routes Operator](#uninstalling-the-static-routes-operator)
  • [Deleting the Egress Gateway Droplet Resource](#deleting-the-egress-gateway-droplet-resource)
  • [FAQ](#faq)
  • [Troubleshooting](#troubleshooting)
  • [Conclusion](#conclusion)

Prerequisites

To complete this tutorial, you will need:

  1. Basic knowledge on how to run and operate DOKS clusters. You can learn more kubernetes.io.
  2. Basic knowledge on how to create and manage Droplets. You can learn more Home – IT Consulting & Software Development.
  3. Basic knowledge and experience with shell commands (e.g. bash).
  4. Kubectl CLI, to interact with Kubernetes clusters. Make sure it is configured to point to your DOKS cluster, as explained kubernetes.io.
  5. Helm (version 3.x is required), to install Crossplane.
  6. Doctl for interacting with cloud provider API.

Step 1 - Introducing Crossplane

The main idea behind Crossplane is infrastructure management the Kubernetes way. It means, you can define and create CRDs using a declarative approach, and let Crossplane deal with the inner details. With Crossplane it's possible to create Droplets, Managed Databases, Load Balancers, even Kubernetes clusters (DOKS), via the the cloud provider provider. Crossplane was designed with flexibility in mind, and it can be extended via providers.

Next, it's important to understand some important concepts behind Crossplace to create the cloud provider resources (e.g., Droplets). There are four main concepts to know about:

  1. Packages allow Crossplane to be extended to include new functionality. You can think of packages the same way as Linux distributions pack and distribute applications. So, Crossplane packages distribute a set of CRDs and associated controllers to provision infrastructure resources.
  2. Providers represent packages that enable Crossplane to provision infrastructure (e.g. the cloud provider Provider).
  3. Managed Resources are Kubernetes custom resources (CRDs) that represent infrastructure primitives. For example, to provision a Droplet, you would use a Droplet CRD.
  4. Composite Resources represents a special kind of custom resource. Main purpose is to compose together more managed resources into a higher level infrastructure unit which can be reused. For example, you can create a composite resource which consists of a managed database (e.g. the cloud provider PostgreSQL) and a firewall resource, acting as a single deployable unit.

Below picture shows a simplified operational overview for Crossplane:

A typical Droplet CRD consumed by Crossplane looks like below:


					apiVersion: compute.do.crossplane.io/v1alpha1
kind: Droplet
metadata:
 name: egress-gw-nyc1
spec:
 forProvider:
 region: nyc1
 size: s-1vcpu-1gb
 image: ubuntu-20-04-x64
 sshKeys:
 - "7e:9c:b7:ee:74:16:a5:f7:62:12:b1:72:dc:51:71:85"
 providerConfigRef:
 name: do-provider-config

Explanations for the above configuration:

  • spec.forProvider – defines all metadata required by the the cloud provider provider to provision a new Droplet, such as: region, size, image, etc. Fields value map directly to the cloud servers specification. Also, if you have SSH keys deployed to your cloud account, you can specify the fingerprint in the sshKeys field from the spec.
  • spec.providerConfigRef – specifies a reference to a provider configuration CRD (explained in [Step 3 – Creating an Egress Gateway using Crossplane](#step-3—creating-an-egress-gateway-using-crossplane)). The provider configuration instructs the Droplet CRD how to connect to the the cloud provider REST API, and what credentials to use (e.g. DO API token).

[info] Hint: You can also check this nice CRD viewer to see all the fields available for the Droplet kind, in a human readable format (available only for latest released version, which is 0.1.0 at this time of writing). Under the hood, Crossplane is delegating the real work to the the cloud provider provider, which in turn will use the provider REST API to create a new droplet based on the requirements from the Droplet CRD spec field. With all features presented above at hand, you are able to build your own cloud platform using one or multiple providers. The possibilities are almost limitless. Please visit the official documentation page for more information about the product and available features. The the cloud provider provider home page for Crossplane is available Home – IT Consulting & Software Development.

In the next step, you will learn how to install and configure Crossplane for your DOKS cluster using Helm.

Step 2 - Installing Crossplane

Crossplane is available as a Helm chart for easy installation, as well as for future upgrades. Follow below steps to install Crossplane, via Helm (version 3.x is required):

  1. Add and update the Crossplane Helm repository:

					helm repo add crossplane-stable https://charts.crossplane.io/stable
helm repo update
  1. Search the crossplane-stable Helm repository for available charts to install:

					helm search repo crossplane-stable

The output looks similar to:


					[secondary_label Output]
NAME CHART VERSION APP VERSION DESCRIPTION
crossplane-stable/crossplane 1.9.0 1.9.0 Crossplane is an open source Kubernetes add-on ...
  1. Deploy Crossplane to your DOKS cluster:

					HELM_CHART_VERSION="1.9.0"
helm install crossplane crossplane-stable/crossplane \
--version "${HELM_CHART_VERSION}" \
--namespace crossplane-system \
-create-namespace

Note: A specific version for the Crossplane Helm chart is used. In this case 1.9.0 is picked, which maps to the 1.9.0 version of the application. It’s good practice in general, to lock on a specific version. This helps to have predictable results, and allows versioning control via Git.

Now, check if the Crossplane Helm chart was deployed to your cluster:


					helm ls -n crossplane-system

The output looks similar to (STATUS column value should be set to deployed):


					[secondary_label Output]
NAME NAMESPACE REVISION UPDATED STATUS CHART APP VERSION
crossplane crossplane-system 1 2022-09-10 20:40:20.903871 +0300 EEST deployed crossplane-1.9.0 1.9.0

Finally, verify the Crossplane deployment status:


					kubectl get deployments -n crossplane-system

The output looks similar to:


					[secondary_label Output]
NAME READY UP-TO-DATE AVAILABLE AGE
crossplane 1/1 1 1 3d19h
crossplane-rbac-manager 1/1 1 1 3d19h

All pods must be up and running (check the READY column). In the next step, a short introduction is given about the static routes operator used in this guide.

Step 3 - Introducing Static Routes Operator

The main role of the Static Routes Operator is to manage entries in the Linux routing table of each worker node based on CRD spec. It is deployed as a DaemonSet, hence it will run on each node of your DOKS cluster.

The diagram below illustrates the operational concept:

Configuring static routes is done via StaticRoute CRDs. A typical example is shown below:


					apiVersion: www.progressiverobot.com/v1
kind: StaticRoute
metadata:
 name: static-route-ifconfig.me
spec:
 destinations:
 - "34.160.111.145"
 gateway: "10.116.0.5"

Explanations for the above configuration:

  • spec.destinations – A list of host IPs (or subnet CIDRs) to route through the gateway.
  • spec.gateway – Gateway IP address used for routing the host(s)/subnet(s), specified in the destinations field.

Because the operator has access to the Linux routing table, special care must be taken and policies set so that only administrators have access. It's very easy to misconfigure the routing table, rendering the DOKS cluster unstable or unusable.

[warning] VERY IMPORTANT TO REMEMBER: You need to make sure not to add static routes containing CIDRs that overlap with the cloud provider REST API endpoints (including DOKS)! Doing so, will affect DOKS cluster functionality (Kubelets), and/or other internal services (e.g. Crossplane).

In the next step, you will learn how to install and configure the static routes operator.

Step 4 - Installing Static Routes Operator

Static routes operator is available as a single manifest file, and it is installed via kubectl. A dedicated namespace, named static-routes, is created as well. Please follow below steps to install the static routes controller:

  1. Deploy the latest version release using kubectl. Below example is using the 1.0.0 version:

					kubectl apply -f https://www.progressiverobot.com/

You can check the latest version in the releases path from the k8s-staticroute-operator GitHub repo.

  1. Check if operator Pods are up and running:

					kubectl get pods -l name=k8s-staticroute-operator -n static-routes

Output looks similar to:


					[secondary_label Output]
NAME READY STATUS RESTARTS AGE
k8s-staticroute-operator-9vp7g 1/1 Running 0 22m
k8s-staticroute-operator-mlfff 1/1 Running 0 22m
  1. Check operator logs – no exceptions should be reported:

					kubectl logs -f ds/k8s-staticroute-operator -n static-routes

Output looks similar to:


					[secondary_label Output]
[2022-08-24 14:42:13,625] kopf._core.reactor.r [DEBUG ] Starting Kopf 1.35.6.
[2022-08-24 14:42:13,625] kopf._core.engines.a [INFO ] Initial authentication has been initiated.
[2022-08-24 14:42:13,626] kopf.activities.auth [DEBUG ] Activity 'login_via_pykube' is invoked.
[2022-08-24 14:42:13,628] kopf.activities.auth [DEBUG ] Pykube is configured in cluster with service account.
[2022-08-24 14:42:13,629] kopf.activities.auth [INFO ] Activity 'login_via_pykube' succeeded.
[2022-08-24 14:42:13,629] kopf.activities.auth [DEBUG ] Activity 'login_via_client' is invoked.
[2022-08-24 14:42:13,631] kopf.activities.auth [DEBUG ] Client is configured in cluster with service account.
[2022-08-24 14:42:13,632] kopf.activities.auth [INFO ] Activity 'login_via_client' succeeded.
[2022-08-24 14:42:13,632] kopf._core.engines.a [INFO ] Initial authentication has finished.
[2022-08-24 14:42:13,789] kopf._cogs.clients.w [DEBUG ] Starting the watch-stream for customresourcedefinitions.v1.apiextensions.k8s.io cluster-wide.
[2022-08-24 14:42:13,791] kopf._cogs.clients.w [DEBUG ] Starting the watch-stream for www.progressiverobot.com cluster-wide.
...

If the output looks like the above, you installed the static routes operator successfully. In the next step, you will learn how to provision your first egress gateway Droplet using Crossplane.

Step 5 - Creating an Egress Gateway using Crossplane

To provision an Egress gateway Droplet on the the cloud provider platform using Kubernetes and Crossplane, you need to follow a few steps:

  1. Install the the cloud provider provider package.
  2. Configure the the cloud provider provider so that it can talk with the provider REST API and manage resources on your behalf.
  3. Provision infrastructure using the designated CRDs, such as Droplet kind, DODatabaseCluster kind, etc.

Next, you will learn how to accomplish each of the above steps, to better understand the concepts and separation of concerns.

Important note: For each step, you will be using the default namespace in order to simplify testing. In practice, is recommended to create the resources in a dedicated namespace, with proper RBAC policies set.

Installing the the cloud provider Provider Package

In Crossplane terms, a provider package is a bundle of assets required by Crossplane to provide additional functionality, such as CRD manifests and associated controller(s). Under the hood, everything is packed in a Docker image and distributed as such.

Typical Crossplane provider package CRD looks like below:


					apiVersion: pkg.crossplane.io/v1
kind: Provider
metadata:
 name: provider-do
spec:
 package: "crossplane/provider-the cloud provider:v0.1.0"

Explanations for the above configuration:

  • spec.package – defines the provider package to download, which in essence is a Docker image, so it follows the standard naming convention.

To install the the cloud provider provider used in this guide, please follow below steps:

  1. Fetch the provider manifest from the container-blueprints repository, using curl:

					curl -O https://www.progressiverobot.com/
  1. Open and inspect the manifest file, using a text editor of your choice (the default values are usually fine, unless you require a specific provider package version). For example, you can use Visual Studio Code, with YAML linting support:

					code do-provider-install.yaml
  1. Apply the manifest using kubectl:

					kubectl apply -f do-provider-install.yaml

Or, directly from the container-blueprints repo (if you're OK with the default values):


					kubectl apply -f https://www.progressiverobot.com/

Finally, check if the provider was installed successfully in your DOKS cluster:


					kubectl get providers

The output looks similar to:


					[secondary_label Output]
NAME INSTALLED HEALTHY PACKAGE AGE
provider-do True True crossplane/provider-the cloud provider:v0.2.0-rc.0.42.g0932045-main 4d17h

The INSTALLED and HEALTHY columns should both report True. Also, the PACKAGE should list the specific version used by the container-blueprints repo – crossplane/provider-the cloud provider:v0.2.0-rc.0.42.g0932045-main.

The provider package CRD used in the containe-blueprints repository is using a specific release from the main branch of the crossplane-contrib/provider-the cloud provider repository. This is due to the fact that it contains some important fixes merged from the following PRs – #60, and #61.

Next, you will learn how to configure the the cloud provider provider to have access to the the cloud provider REST API and manage resources on your behalf.

Configuring the the cloud provider Provider

The the cloud provider provider package installed previously needs a ProviderConfig CRD to operate properly. In order to perform REST operations, it needs to authenticate against the the cloud provider REST API endpoint. For that, a valid DO API token is required, stored in a Kubernetes secret (as a base64 encoded value).

Typical ProviderConfig CRD looks like below:


					apiVersion: do.crossplane.io/v1alpha1
kind: ProviderConfig
metadata:
 name: do-provider-config
spec:
 credentials:
 source: Secret
 secretRef:
 namespace: crossplane-system
 name: do-api-token
 key: token

Explanations for the above configuration:

  • spec.credentials.source – defines a source where credentials are stored (e.g. Kubernetes Secret).
  • spec.credentials.secretRef – tells the provider how to access the secret, such as what namespace it was created, its name, and what key contains the DO API token value as a base64 encoded string.

To install the the cloud provider provider configuration used in this guide, please follow below steps:

  1. Fetch the provider configuration manifest from the container-blueprints repository, using curl:

					curl -O https://www.progressiverobot.com/
  1. Open and inspect the manifest file, using a text editor of your choice. For example, you can use Visual Studio Code, with YAML linting support:

					code do-provider-config.yaml
  1. Replace the <> placeholders in the do-api-token Kubernetes Secret CRD. Please run below command, to generate the base64 encoded string from your DO API token:

					echo "&lt;YOUR_DO_API_TOKEN_HERE&gt;" | base64
  1. Save the provider configuration file, and apply using kubectl:

					kubectl apply -f do-provider-config.yaml

Finally, check if the provider configuration resource was created successfully:


					kubectl get providerconfigs -o wide

The output looks similar to:


					[secondary_label Output]
NAME AGE SECRET-NAME
do-provider-config 4d18h do-api-token

If the output looks like the above, you successfully configured the the cloud provider provider. Notice the SECRET-NAME column value – it references the secret storing your DO API token.

Please note that all the steps taken so far must be performed only once. Once a provider is installed and configured, you can reference it in any resource you want to create, such as Droplets, managed databases, etc. The only intervention required over time is when you need to upgrade a provider package to get new functionality or if you need to update your DO API token.

Next, you will take the final step and provision the egress gateway droplet for your egress setup.

Provisioning the Egress Gateway Droplet Resource

The egress gateway Droplet and DOKS cluster must be in the same VPC (or on the same network) for the whole setup to work.

Now that the the cloud provider provider is installed and properly configured, you can create the Droplet resource to act as an egress gateway for the demo used in this blueprint.

The Crossplane Droplet CRD used in this blueprint looks like below:


					apiVersion: compute.do.crossplane.io/v1alpha1
kind: Droplet
metadata:
 name: egress-gw-nyc1
spec:
 forProvider:
 region: nyc1
 size: s-1vcpu-1gb
 image: ubuntu-20-04-x64
 vpcUuid: 4b5e125e-c52e-4578-93a7-01341ee927ac
 sshKeys:
 - "7e:9c:b7:ee:74:16:a5:f7:62:12:b1:72:dc:51:71:85"
 userData: |
 #!/usr/bin/env bash
 # Install dependencies
 echo iptables-persistent iptables-persistent/autosave_v4 boolean true | debconf-set-selections
 echo iptables-persistent iptables-persistent/autosave_v6 boolean true | debconf-set-selections
 apt-get update
 apt-get -y install iptables iptables-persistent curl

 # Enable IP forwarding
 echo "net.ipv4.ip_forward=1" &gt;&gt; /etc/sysctl.conf
 sysctl -p /etc/sysctl.conf

 # Configure iptables for NAT
 PRIVATE_NETWORK_INTERFACE_IP="$(curl -s http://169.254.169.254/metadata/v1/interfaces/private/0/ipv4/address)"
 PRIVATE_NETWORK_CIDR="$(ip route show src $PRIVATE_NETWORK_INTERFACE_IP | awk '{print $1}')"
 PUBLIC_INTERFACE_NAME="$(ip route show default | awk '{print $5}')"
 iptables -t nat -A POSTROUTING -s "$PRIVATE_NETWORK_CIDR" -o "$PUBLIC_INTERFACE_NAME" -j MASQUERADE
 iptables-save &gt; /etc/iptables/rules.v4
 providerConfigRef:
 name: do-provider-config

The fields meaning is the same as explained at the beginning of this blueprint guide, when Crossplane was [introduced](#step-1—introducing-crossplane)). The only exception is the spec.forProvider.userData field. What this field does is it allows you to specify custom cloud-init scripts for the Droplet (e.g., Bash scripts, denoted by the first line value – #!/usr/bin/env bash).

In the above example, the cloud init script main role is to initialize the Droplet to act as a NAT gateway. The example is heavily based on this guide provided by the cloud provider.

  1. The first line denotes the fact that the cloud init script needs to be interpreted as a Bash script – #!/usr/bin/env bash.
  2. Next, the required packages are installed, such as: iptables, iptables-persistent (persists iptables rules on reboot), etc. Please bear in mind that the installation commands are Linux distribution specific (above example is Ubuntu specific, which in turn is based on Debian).
  3. Then, IP forwarding is enabled for the Linux Kernel via the net.ipv4.ip_forward sysctl setting. Configuration is persisted in the /etc/sysctl.conf file to survive machine reboots.
  4. Next, iptables is configured with required NAT rules, to provide egress functionality in combination with IP forwarding.
  5. Finally, NAT rules are saved using the iptables-save command, to persist on reboots.

To create the egress gateway Droplet via Kubernetes, please follow below steps:

  1. Fetch the Droplet CRD manifest from the container-blueprints repository, using curl:

					curl -O https://www.progressiverobot.com/
  1. Open and inspect the manifest file, using a text editor of your choice (the default values are usually fine, unless you require something specific). For example, you can use Visual Studio Code, with YAML linting support:

					code egress-gw-droplet.yaml

If you have specific SSH keys you want to add at Droplet creation time, you can do so by uncommenting the sshKeys field from the spec. Then, replace the <> placeholders with your SSH key fingerprint. To list the available SSH keys associated with your account and their fingerprint, you can do so by issuing the following command – doctl compute ssh-key list.

The egress gateway Droplet and DOKS cluster must be in the same VPC. Use the following command to get your VPC ID – doctl vpcs list and set this by uncommenting the vpcUuid field from the spec.

  1. Save and apply the manifest using kubectl:

					kubectl apply -f egress-gw-droplet.yaml

Or, directly from the container-blueprints repo (if you're OK with the default values):


					kubectl apply -f https://www.progressiverobot.com/

Finally, check if the Droplet Kubernetes resource was created successfully:


					kubectl get droplets -o wide

The output looks similar to:


					[secondary_label Output]
NAME PRIVATE IPV4 PUBLIC IPV4 READY REGION SIZE SYNCED
egress-gw-nyc1 10.116.0.4 192.81.213.125 True nyc1 s-1vcpu-1gb True
  • Please bear in mind that it takes some time for the Droplet to be provisioned, so please be patient.
  • The PRIVATE IPV4 and PUBLIC IPV4 columns will receive values only after the Droplet is successfully provisioned.
  • You can always check how the Droplet resource is progressing, or if something goes wrong by inspecting the Events output from below command:

					kubectl describe droplet egress-gw-nyc1

The READY and SYNCED columns should print True. If the output looks like above, you configured the Droplet CRD successfully. Also, if you navigate to the Droplets web panel from your cloud account, you should see the new resource created. You should receive an email as well, with additional details about your newly created Droplet.

Finally, you can check if the cloud init script ran successfully, and did the required changes to enable IP forwarding and NAT functionality. Please follow below steps (all commands must be run as root, or via sudo):

  1. Check if IP forwarding is set:

					cat /proc/sys/net/ipv4/ip_forward
# Should output: 1, meaning it's enabled
  1. Check if NAT is set via iptables:

					iptables -L -t nat

The output looks similar to (the POSTROUTING chain should print the MASQUERADE target for your VPC subnet):


					[secondary_label Output]
...
Chain POSTROUTING (policy ACCEPT)
target prot opt source destination
MASQUERADE all -- 10.116.0.0/20 anywhere

If all checks pass, you configured the egress gateway Droplet successfully. Next, you will learn how to define and create static routes for single as well as multiple destinations using the egress gateway created earlier via Crossplane.

Step 6 - Configuring Static Routes for your Egress Gateway

The [sample CRDs](assets/manifests/static-routes/) provided in this blueprint create a static route to two different websites which report back your public IP – ifconfig.me/ip, and ipinfo.io/ip.

To test the setup, download each sample manifest:


					# Example for ifconfig.me
curl -O https://www.progressiverobot.com/
# Example for ipinfo.io
curl -O https://www.progressiverobot.com/

After downloading the manifests, replace the <> placeholders in each manifest file. To find out the private IPv4 address of your egress gateway droplet, please run the below command (assuming the Droplet name is egress-gw-nyc1):


					kubectl get droplet egress-gw-nyc1 -o jsonpath="{.status.atProvider.privateIPv4}"

Next, save changes and apply each manifest using kubectl:


					# Example for ifconfig.me
kubectl apply -f ifconfig-me-example.yaml
# Example for ipinfo.io
kubectl apply -f ipinfo-io-example.yaml

The above command will create the static route custom resources in the default namespace. In production environments (and not only), it's best to have a dedicated namespace with RBAC policies set.

Next, check if the static route resources were created:


					kubectl get staticroutes -o wide

The output looks similar to (egress gateway has private IP 10.116.0.5 in below example):


					NAME DESTINATIONS GATEWAY AGE
static-route-ifconfig.me ["34.160.111.145"] 10.116.0.5 7m2s
static-route-ipinfo.io ["34.117.59.81"] 10.116.0.5 4s

Next, check if the static route resources were created:


					kubectl get staticroutes -o wide

The output looks similar to:


					NAME DESTINATIONS GATEWAY AGE
static-route-ifconfig.me ["34.160.111.145"] 10.116.0.5 7m2s
static-route-ipinfo.io ["34.117.59.81"] 10.116.0.5 4s

Finally, check if the custom static routes were created on each worker node, after SSH-ing:


					route -n

The output looks similar to (the irrelevant lines were omitted from the output for better visibility):


					[secondary_label Output]
Kernel IP routing table
Destination Gateway Genmask Flags Metric Ref Use Iface
0.0.0.0 206.81.0.1 0.0.0.0 UG 0 0 0 eth0
...
34.117.59.81 10.116.0.5 255.255.255.255 UGH 0 0 0 eth1
34.160.111.145 10.116.0.5 255.255.255.255 UGH 0 0 0 eth1
  1. You can check each static route status by describing the resource. Taking static-route-ifconfig.me as an example:

					kubectl describe staticroute static-route-ifconfig.me

The output looks similar to (only last relevant lines are shown for simplicity):


					[secondary_label Output]
 Spec:
 Destinations:
 34.160.111.145
 Gateway: 10.116.0.4
 Status:
 create_fn:
 Destination: 34.160.111.145
 Gateway: 10.116.0.4
 Status: Ready
 Events: &lt;none&gt;

Looking at the above output, you can see each route details, including status (Ready or NotReady), in the Status field.

  1. To see all events emitted by the static routes controller, you can use the below command:

					kubectl get events -n static-routes
  1. For further troubleshooting, you can check the static routes controller logs:

					kubectl logs -n static-routes ds/k8s-staticroute-operator &gt; k8s-staticroute-operator.log
code k8s-staticroute-operator.log

Step 7 - Testing the DOKS Cluster Egress Setup

To test your egress setup, you need to check if all the requests originating from your DOKS cluster travel via a single node – the Egress Gateway. The simplest way to test, is by making a curl request to ifconfig.me/ip, and see if the response contains your Egress Gateway public IP address.

First, you need to create the curl-test pod in your DOKS cluster (the default namespace is used):


					kubectl apply -f https://www.progressiverobot.com/

Verify that the pod is up and running (in the default namespace):


					kubectl get pods

The output looks similar to (curl-test pod Status should be Running):


					[secondary_label Output]
NAME READY STATUS RESTARTS AGE
curl-test 1/1 Running 0 7s

Then, perform a HTTP request to ifconfig.me, from the curl-test pod:


					kubectl exec -it curl-test -- curl ifconfig.me

The output looks similar to:


					[secondary_label Output]
192.81.213.125

The resulting IP address that gets printed should be the public IP address that was assigned to your egress gateway droplet. You can check your NAt gateway Droplet public IPv4 address via kubectl:


					kubectl get droplet egress-gw-nyc1 -o jsonpath="{.status.atProvider.publicIPv4}"

Step 8 - Configuring the Static Routes Controller to Egress All Cluster Traffic

You need to make sure not to add static routes containing CIDRs that overlap with the cloud provider REST API endpoints (including DOKS)! Doing so, will affect DOKS cluster functionality (Kubelets), and/or other internal services (e.g. Crossplane).

So far, you configured the static routes controller to egress cluster traffic for specific destinations only. But, you can also use the static routes controller to egress cluster traffic for multiple destinations (or public CIDRs) as well (some limitations apply, though, and explained below).

If changing the default gateway in the Linux routing table on each node to point to the custom egress gateway private IP, then you can route all outbound traffic via the custom gateway. But, there's an issue with this approach – the internal services running in the cluster that need access to the cloud provider public API will not work anymore, thus making it unstable. Also, resources provisioned via Crossplane won't work as well.

To solve the above issue, you can use another approach where you create static routes for all public CIDRs, except the ones that overlap with cloud provider API public endpoints. There is a ready-to-use sample provided in this tutorial that allows us to achieve this goal, called public-egress-example.

Usually, you need to set this only once, but please be mindful of what IP ranges you use. The static routes controller cannot distinguish if some ranges overlap or not or if some are overlapping with the cloud provider REST API public endpoints. Just to be safe, you can have a small cluster somewhere, which is safe to discard if something goes bad. The overlapping CIDRs are already commented in the provided example. You can subdivide those CIDRs even further and remove the exact ranges that overlap with the cloud provider REST API endpoints.

Follow the below steps to apply the public CIDRs example from this guide:

  1. Download the public-egress.yaml file to your local machine:

					curl -O https://www.progressiverobot.com/
  1. Open and inspect the manifest file using a text editor of your choice (the default values are usually fine unless you require something specific). For example, you can use Visual Studio Code, with YAML linting support:

					code public-egress-example.yaml
  1. Replace the <> placeholders for the gateway spec field, then save and apply the manifest using kubectl:

					kubectl apply -f public-egress-example.yaml

Now, check if all routes were created by SSH-ing to each node, and run route -n. All entries from the public-egress.yaml manifest should be present. Also, you can use kubectl describe on the resource and check its status.

How to check all public IP address ranges used by the cloud provider? There are two options available:

  1. The ipinfo.io database of known public IP address ranges for the cloud provider.
  2. The SecOps-Institute GitHub page (stores a list of all the cloud provider Servers using the ASN Numbers from RADB Lookups).

Cleaning Up

If you want to clean up all the resources associated with this guide, you can do so for each major component as follows.

Uninstalling the Static Routes Operator

To clean up the operator and associated resources, please run the following kubectl command (make sure you're using the same release version as in the install step):


					kubectl delete -f https://www.progressiverobot.com/

Note: Above command will also delete the associated namespace (static-routes). Make sure to backup your CRDs first, if needed later.

The output looks similar to:


					[secondary_label Output]
customresourcedefinition.apiextensions.k8s.io "www.progressiverobot.com" deleted
serviceaccount "k8s-staticroute-operator" deleted
clusterrole.rbac.authorization.k8s.io "k8s-staticroute-operator" deleted
clusterrolebinding.rbac.authorization.k8s.io "k8s-staticroute-operator" deleted
daemonset.apps "k8s-staticroute-operator" deleted

Check the routes on each worker node after SSH-ing:


					route -n

The custom static routes should not be present in the routing table output.

Finally, the curl-test pod should report back the public IP of the worker node where it runs:


					# Inspect the node where the curl-test Pod runs:
kubectl get pod curl-test -o wide

The output looks similar to (write down the node name from the NODE column):


					[secondary_label Output]
NAME READY STATUS RESTARTS AGE IP NODE NOMINATED NODE READINESS GATES
curl-test 1/1 Running 2 (45m ago) 165m 10.244.0.140 basicnp-7micg &lt;none&gt; &lt;none&gt;

Above example reports – basicnp-7micg.

Check the worker node public IP:


					kubectl get nodes -o wide

The output looks similar to (note the public IP of the associated node where the curl-test Pod runs):


					[secondary_label Output]
NAME STATUS ROLES AGE VERSION INTERNAL-IP EXTERNAL-IP OS-IMAGE KERNEL-VERSION CONTAINER-RUNTIME
basicnp-7micg Ready &lt;none&gt; 3h20m v1.23.9 10.116.0.2 206.189.231.90 Debian GNU/Linux 10 (buster) 5.10.0-0.bpo.15-amd64 containerd://1.4.13
basicnp-7micw Ready &lt;none&gt; 3h20m v1.23.9 10.116.0.3 206.81.2.154 Debian GNU/Linux 10 (buster) 5.10.0-0.bpo.15-amd64 containerd://1.4.13

Above example reports – 206.189.231.90.

Exec the ifconfig.me/ip curl:


					kubectl exec -it curl-test -- curl ifconfig.me/ip

The output looks similar to:


					[secondary_label Output]
206.189.231.90

The response should include the original public IP of the worker node where the curl-test Pod runs.

Deleting the Egress Gateway Droplet Resource

Removing the egress gateway droplet is just a matter of deleting the associated CRD (please bear in mind that this process is destructive, and you cannot revert):


					kubectl delete -f https://www.progressiverobot.com/

After running the above command, the associated Droplet resource should be destroyed and removed from your cloud account.

Troubleshooting

Kubectl Freezes on Object Deletion

Whenever you delete a resource in Kubernetes, the associated controller puts a finalizer on the respective object in the metadata field. Bellow snippet below shows the Finalizers field in the Static Route CRD:


					Name: www.progressiverobot.com
Namespace:
Labels: &lt;none&gt;
Annotations: provider: cloud provider API Version: apiextensions.k8s.io/v1
Kind: CustomResourceDefinition
Metadata:
 Creation Timestamp: 2022-09-19T15:05:34Z
 Deletion Timestamp: 2022-09-27T14:51:10Z
 Finalizers:
 customresourcecleanup.apiextensions.k8s.io
...

Kubernetes checks for the finalizer field first and if found, it will not delete the resource from the cluster until the associated controller finishes its job internally. If everything goes as planned, the controller removes the finalizer field from the object, and then and only then, Kubernetes moves forward with the actual deletion of the resource.

The main role of a finalizer is to allow the associated controller to finish its job internally before actual object deletion.

If, for some reason, controller logic is unable to process the request and remove the finalizer field, the resource hangs in a Terminating state. Then, kubectl freezes because the Kubernetes API cannot process the request.

As a side effect, this warning is reported in the static routes controller logs:


					[2022-09-27 14:58:11,405] kopf._core.reactor.o [WARNING ] Non-patchable resources will not be served: {www.progressiverobot.com}

Why this happens, and how do I recover?

It can happen for various reasons – one such example is when the controller is down because of an upgrade, hence it is unable to process requests. In this case the CRD remains in an inconsistent state, and the only way to recover is via:


					kubectl patch staticroute &lt;YOUR_STATIC_ROUTE_RESOURCE_NAME_HERE&gt; -p '{"metadata": {"finalizers": []}}' --type merge

The above command removes the finalizer field from the resource, thus allowing Kubernetes to proceed with actual object deletion. Consequently, the Linux routing table still holds the old route entries. You have several options here:

  1. Manually delete the old entries. This can be a daunting task if many routes and nodes are implied.
  2. Restart the operator and allow it to remove the finalizers. Issue the following command to perform a rollout for the static routes operator DaemonSet – kubectl rollout restart -n static-routes ds/k8s-staticroute-operator.
  3. As a last resort, re-deploy the static routes controller and re-apply the original static route CRDs. Then, delete the CRDs. If everything goes as planned, the static routes controller takes care of the rest.

Conclusion

In this tutorial, you learned how to use Crossplane to create and manage an egress Gateway resource for your DOKS cluster. This way, external services (e.g. database), will see a single source IP in the packets coming from your DOKS cluster, thus making firewall rules management easier on the other end. Also, you learned how to use the static routes operator to manage specific routes for the egress functionality.

Learn More
