Introduction
Puppet is a configuration management tool that system administrators use to automate the processes involved in maintaining a company's IT infrastructure. Writing individual Puppet manifest files is sufficient for automating simple tasks. However, when you have an entire workflow to automate, it is ideal to create and use a Puppet module instead. A Puppet module is just a collection of manifests along with files that those manifests require, neatly bundled into a reusable and shareable package.
WordPress is a very popular blogging platform. As an administrator, you might find yourself installing WordPress and its dependencies (Apache, PHP, and MySQL) very often. This installation process is a good candidate for automation, and today we create a Puppet module that does just that.
What This Tutorial Includes
In this tutorial you will create a Puppet module that can perform the following activities:
- Install Apache and PHP
- Install MySQL
- Create a database and a database user on MySQL for WordPress
- Install and configure WordPress
You will then create a simple manifest that uses the module to set up WordPress on Ubuntu 14.04. At the end of this tutorial, you will have a reusable WordPress module and a working WordPress installation on the server.
Prerequisites
You will need the following:
- Ubuntu 14.04 server
- A sudo user
- You shoud understand how to manage WordPress once you get to the control panel setup. If you need help with that, check the later parts of this tutorial
Step 1 — Install Puppet in Standalone Mode
To install Puppet using <^>apt-get<^>, the Puppet Labs Package repository has to be added to the list of available repositories. Puppet Labs has a Debian package that does this. The name of this package depends on the version of Ubuntu you are using. As this tutorial uses Ubuntu 14.04, Trusty Tahr, you have to download and install puppetlabs-release-trusty.deb.
Create and move into your Downloads directory:
~~~~
mkdir ~/Downloads
cd ~/Downloads
~~~~
Get the package:
~~~~
wget https://apt.puppetlabs.com/puppetlabs-release-trusty.deb
sudo dpkg -i puppetlabs-release-trusty.deb
~~~~
You can now install Puppet using apt-get.
~~~~
sudo apt-get update
sudo apt-get install puppet
~~~~
Puppet is now installed. You can check by typing in:
~~~~
sudo puppet –version
~~~~
It should print Puppet's version. At the time of this writing, the latest version is 3.7.1.
Note: If you see a warning message about <^>templatedir<^>, check the solution in Step 2.
Step 2 - Install Apache and MySQL Modules
Managing Apache and MySQL are such common activities that PuppetLabs has its own modules for them. We'll use these modules to install and configure Apache and MySQL.
You can list all the Puppet modules installed on your system using the following command:
~~~~
sudo puppet module list
~~~~
You will find no modules currently installed.
You might see a warning message that says:
~~~~
Warning: Setting templatedir is deprecated. See http://links.puppetlabs.com/env-settings-deprecations
(at /usr/lib/ruby/vendor_ruby/puppet/settings.rb:1071:in `each')
~~~~
To remove this warning, use <^>nano<^> to edit the <^>puppet.conf<^> file, and comment out the <^>templatedir<^> line:
~~~~
sudo nano /etc/puppet/puppet.conf
~~~~
After the edits, the file should have the following contents. You are just commenting out the <^>templatedir<^> line:
~~~~
[main]
logdir=/var/log/puppet
vardir=/var/lib/puppet
ssldir=/var/lib/puppet/ssl
rundir=/var/run/puppet
factpath=$vardir/lib/facter
<^>#templatedir=$confdir/templates<^>
[master]
ssl_client_header = SSL_CLIENT_S_DN
ssl_client_verify_header = SSL_CLIENT_VERIFY
~~~~
That should remove the warning message.
Install the PuppetLabs Apache and MySQL modules:
~~~~
sudo puppet module install puppetlabs-apache
sudo puppet module install puppetlabs-mysql
~~~~
Verify the installation by listing the modules again:
~~~~
sudo puppet module list
~~~~
You should be able to see the Apache and MySQL modules in the list.
~~~~
/etc/puppet/modules
├── puppetlabs-apache (v1.1.1)
├── puppetlabs-concat (v1.1.1)
├── puppetlabs-mysql (v2.3.1)
└── puppetlabs-stdlib (v4.3.2)
~~~~
Step 3 - Create a New Module for WordPress
Create a new directory to keep all your custom modules.
~~~~
mkdir ~/MyModules
cd ~/MyModules
~~~~
Let us call our module <^>do-wordpress<^>. Generate the generic new module:
~~~~
puppet module generate do-wordpress –skip-interview
~~~~
If you don't include the <^>–skip-interview<^> flag, the command will be interactive, and will prompt you with various questions about the module to populate the <^>metadata.json<^> file.
At this point a new directory named <^>do-wordpress<^> has been created. It contains boilerplate code and a directory structure that is necessary to build the module.
Edit the <^>metadata.json<^> file to replace <^>puppetlabs-stdlib<^> with <^>puppetlabs/stdlib<^>.
~~~~
nano ~/MyModules/do-wordpress/metadata.json
~~~~
This edit is required due a currently open bug in Puppet. After the change, your <^>metadata.json<^> file should look like this:
~~~~
{
"name": "do-wordpress",
"version": "0.1.0",
"author": "do",
"summary": null,
"license": "Apache 2.0",
"source": "",
"project_page": null,
"issues_url": null,
"dependencies": [
{"name":<^>"puppetlabs/stdlib"<^>,"version_requirement":">= 1.0.0"}
]
}
~~~~
Step 4 - Create a Manifest to Install Apache and PHP
Use <^>nano<^> to create and edit a file named <^>web.pp<^> in the <^>manifests<^> directory, which will install Apache and PHP:
~~~~
nano ~/MyModules/do-wordpress/manifests/web.pp
~~~~
Install Apache and PHP with default parameters. We use <^>prefork<^> as the MPM (Multi-Processing Module) to maximize compatibility with other libraries.
Add the following code to the file exactly:
~~~~
class wordpress::web {
class {'apache':
mpm_module => 'prefork'
}
class {'::apache::mod::php': }
}
~~~~
Step 5 - Create a File to Store Configuration Variables
Use <^>nano<^> to create and edit a file named <^>conf.pp<^> in the <^>manifests<^> directory.
~~~~
nano ~/MyModules/do-wordpress/manifests/conf.pp
~~~~
This file is the one place where you should set custom configuration values such as passwords and names. Every other configuration file on the system will pull its values from this file.
In the future, if you need to change the WordPress/MySQL configuration, you will have to change only this file.
Add the following code to the file. Make sure you replace the database values with the custom information you want to use with WordPress. You will most likely want to leave <^>db_host<^> set to <^>localhost<^>. You should change the <^>root_password<^> and <^>db_user_password<^>.
Variables that you can or should edit are marked in <^>red<^>:
~~~~
class wordpress::conf {
$root_password = '<^>password<^>'
$db_name = '<^>wordpress<^>'
$db_user = '<^>wp<^>'
$db_user_password = '<^>password<^>'
$db_host = '<^>localhost<^>'
$db_user_host = "${db_user}@${db_host}"
$db_user_host_db = "${db_user}@${db_host}/${db_name}.*"
}
~~~~
Step 6 - Create a Manifest for MySQL
Use <^>nano<^> to create and edit a file named <^>db.pp<^> in the <^>manifests<^> directory:
~~~~
nano ~/MyModules/do-wordpress/manifests/db.pp
~~~~
This manifest does the following:
- Installs MySQL server
- Sets the root password for MySQL server
- Creates a database for WordPress
- Creates a user for WordPress
- Grants privileges to the user to access the database
- Installs MySQL client and bindings for various languages
All of the above actions are performed by the classes ::mysql::server and ::mysql::client.
Add the following code to the file exactly as shown. Inline comments are included to provide a better understanding:
~~~~
class wordpress::db {
class { '::mysql::server':
root_password => $wordpress::conf::root_password,
databases => {
"${wordpress::conf::db_name}" => {
ensure => 'present',
charset => 'utf8'
}
},
users => {
"${wordpress::conf::db_user_host}" => {
ensure => present,
password_hash => mysql_password("${wordpress::conf::db_user_password}")
}
},
grants => {
"${wordpress::conf::db_user_host_db}" => {
ensure => 'present',
options => ['GRANT'],
privileges => ['ALL'],
table => "${wordpress::conf::db_name}.*",
user => "${wordpress::conf::db_user_host}",
}
},
}
class { '::mysql::client':
require => Class['::mysql::server'],
bindings_enable => true
}
}
~~~~
Step 7 - Download the Latest WordPress
Download the latest WordPress installation bundle from the official website using <^>wget<^> and store it in the <^>files<^> directory.
Create and move to a new directory:
~~~~
mkdir ~/MyModules/do-wordpress/files
cd ~/MyModules/do-wordpress/files
~~~~
Download the files:
~~~~
wget http://wordpress.org/latest.tar.gz
~~~~
Step 8 - Create a Template for wp-config.php
You might already know that WordPress needs a <^>wp-config.php<^> file that contains information about the MySQL database that it is allowed to use. A template is used so that Puppet can generate this file with the right values.
Create a new directory named <^>templates<^>.
~~~~
mkdir ~/MyModules/do-wordpress/templates
~~~~
Move into the <^>/tmp<^> directory:
~~~~
cd /tmp
~~~~
Extract the WordPress files:
~~~~
tar -xvzf ~/MyModules/do-wordpress/files/latest.tar.gz # Extract the tar
~~~~
The <^>latest.tar.gz<^> file that you downloaded contains a <^>wp-config-sample.php<^> file. Copy the file to the <^>templates<^> directory as <^>wp-config.php.erb<^>.
~~~~
cp /tmp/wordpress/wp-config-sample.php ~/MyModules/do-wordpress/templates/wp-config.php.erb
~~~~
Clean up the <^>/tmp<^> directory:
~~~~
rm -rf /tmp/wordpress # Clean up
~~~~
Edit the wp-config.php.erb file using <^>nano<^>.
~~~~
nano ~/MyModules/do-wordpress/templates/wp-config.php.erb
~~~~
Use the variables defined in <^>conf.pp<^> to set the values for <^>DB_NAME<^>, <^>DB_USER<^>, <^>DB_PASSWORD<^> and <^>DB_HOST<^>. You can use the exact settings shown below, which will pull in your actual variables from the <^>conf.pp<^> file we created earlier. The items marked in <^>red<^> are the exact changes that you need to make on the four database-related lines.
Ignoring the comments, your file should look like this:
~~~~
<?php
define('DB_NAME', '<^><%= scope.lookupvar('wordpress::conf::db_name') %><^>');
define('DB_USER', '<^><%= scope.lookupvar('wordpress::conf::db_user') %><^>');
define('DB_PASSWORD', '<^><%= scope.lookupvar('wordpress::conf::db_user_password') %><^>');
define('DB_HOST', '<^><%= scope.lookupvar('wordpress::conf::db_host') %><^>');
define('DB_CHARSET', 'utf8');
define('DB_COLLATE', '');
define('AUTH_KEY', 'put your unique phrase here');
define('SECURE_AUTH_KEY', 'put your unique phrase here');
define('LOGGED_IN_KEY', 'put your unique phrase here');
define('NONCE_KEY', 'put your unique phrase here');
define('AUTH_SALT', 'put your unique phrase here');
define('SECURE_AUTH_SALT', 'put your unique phrase here');
define('LOGGED_IN_SALT', 'put your unique phrase here');
define('NONCE_SALT', 'put your unique phrase here');
$table_prefix = 'wp_';
define('WP_DEBUG', false);
if ( !defined('ABSPATH') )
define('ABSPATH', dirname(__FILE__) . '/');
require_once(ABSPATH . 'wp-settings.php');
~~~~
Step 9 - Create a Manifest for WordPress
Use <^>nano<^> to create and edit a file named <^>wp.pp<^> in the manifests directory:
~~~~
nano ~/MyModules/do-wordpress/manifests/wp.pp
~~~~
This manifest performs the following actions:
- Copies the contents of the WordPress installation bundle to <^>/var/www/<^>. This has to be done because the default configuration of Apache serves files from <^>/var/www/<^>
- Generates a <^>wp-config.php<^> file using the template
Add the following code to the file exactly as shown:
~~~~
class wordpress::wp {
file { '/tmp/latest.tar.gz':
ensure => present,
source => "puppet:///modules/wordpress/latest.tar.gz"
}
exec { 'extract':
cwd => "/tmp",
command => "tar -xvzf latest.tar.gz",
require => File['/tmp/latest.tar.gz'],
path => ['/bin'],
}
exec { 'copy':
command => "cp -r /tmp/wordpress/* /var/www/",
require => Exec['extract'],
path => ['/bin'],
}
file { '/var/www/wp-config.php':
ensure => present,
require => Exec['copy'],
content => template("wordpress/wp-config.php.erb")
}
}
~~~~
Step 10 - Create init.pp, a Manifest that Integrates the Other Manifests
Every Puppet module needs to have a file named <^>init.pp<^>. When an external manifest includes your module, the contents of this file will be executed. The puppet module generate command created a generic version of this file for you already.
Edit <^>init.pp<^> using nano:
~~~~
nano ~/MyModules/do-wordpress/manifests/init.pp
~~~~
Let the file have the following contents.
You can leave the commented explanations and examples at the top. There should be an empty block for the wordpress class. Add the contents shown here so the wordpress block looks like the one shown below. Make sure you get the brackets nested correctly.
Inline comments are included to explain the settings:
~~~~
class wordpress {
class { 'wordpress::conf': }
class { 'wordpress::web': }
class { 'wordpress::db': }
class { 'wordpress::wp':
require => Notify['Apache Installation Complete']
}
notify { 'MySQL Installation Complete':
require => Class['wordpress::db']
}
notify { 'Apache Installation Complete':
require => Class['wordpress::web']
}
notify { 'Wordpress Installation Complete':
require => Class['wordpress::wp']
}
}
~~~~
Step 11 - Build the WordPress Module
The module is now ready to be built. Move into the *MyModules* directory:
~~~~
cd ~/MyModules
~~~~
Use the puppet module build command to build the module:
~~~~
sudo puppet module build do-wordpress
~~~~
You should see the following output from a successful build:
~~~~
Notice: Building /home/user/MyModules/do-wordpress for release
Module built: /home/user/MyModules/do-wordpress/pkg/do-wordpress-0.1.0.tar.gz
~~~~
The module is now ready to be used and shared. You will find the installable bundle in the module's <^>pkg<^> directory.
Step 12 - Install the WordPress Module
To use the module, it has to be installed first. Use the puppet module install command.
~~~~
sudo puppet module install ~/MyModules/do-wordpress/pkg/do-wordpress-0.1.0.tar.gz
~~~~
After installation, when you run the sudo puppet module list command, you should see an output similar to this:
~~~~
/etc/puppet/modules
├── do-wordpress (v0.1.0)
├── puppetlabs-apache (v1.1.1)
├── puppetlabs-concat (v1.1.1)
├── puppetlabs-mysql (v2.3.1)
└── puppetlabs-stdlib (v4.3.2)
~~~~
Now that it's installed, you should reference this module as do-wordpress for any Puppet commands.
Updating or Uninstalling the Module
If you receive installation errors, or if you notice configuration problems with WordPress, you will likely need to make changes in one or more of the manifest and related files we created earlier in the tutorial.
Or, you may simply want to uninstall the module at some point.
To update or uninstall the module, use this command:
~~~~
sudo puppet module uninstall do-wordpress
~~~~
If you just wanted to uninstall, you're done.
Otherwise, make the changes you needed, then rebuild and reinstall the module according to Steps 11-12.
Step 13 - Use the Module in a Standalone Manifest File to Install WordPress
To use the module to install WordPress, you have to create a new manifest, and apply it.
Use <^>nano<^> to create and edit a file named install-wp.pp in the <^>/tmp<^> directory (or any other directory of your choice).
~~~~
nano /tmp/install-wp.pp
~~~~
Add the following contents to the file exactly as shown:
~~~~
class { 'wordpress':
}
~~~~
Apply the manifest using puppet apply. This is the step that gets WordPress up and running on your server:
~~~~
sudo puppet apply /tmp/install-wp.pp
~~~~
It's fine to see a warning or two.
This will take a while to run, but when it completes, you will have WordPress and all its dependencies installed and running.
The final few successful installation lines should look like this:
~~~~
Notice: /Stage[main]/Apache/File[/etc/apache2/mods-enabled/authn_core.load]/ensure: removed
Notice: /Stage[main]/Apache/File[/etc/apache2/mods-enabled/status.load]/ensure: removed
Notice: /Stage[main]/Apache/File[/etc/apache2/mods-enabled/mpm_prefork.load]/ensure: removed
Notice: /Stage[main]/Apache/File[/etc/apache2/mods-enabled/status.conf]/ensure: removed
Notice: /Stage[main]/Apache/File[/etc/apache2/mods-enabled/mpm_prefork.conf]/ensure: removed
Notice: /Stage[main]/Apache::Service/Service[httpd]: Triggered 'refresh' from 55 events
Notice: Finished catalog run in 55.91 seconds
~~~~
You can open a browser and visit http://<^>server-IP<^>/. You should see the WordPress welcome screen.
From here, you can configure your WordPress control panel normally.
Deploying to Multiple Servers
If you are running Puppet in an Agent-Master configuration and want to install WordPress on one or more remote machines, all you have to do is add the line class {'wordpress':} to the node definitions of those machines. To learn more about Agent-Master configuration and node definitions, you can refer to this tutorial:
Conclusion
With this tutorial, you have learned to create your own Puppet module that sets up WordPress for you. You could further build on this to add support for automatically installing certain themes and plugins. Finally, when you feel your module could be useful for others as well, you can publish it on Puppet Forge.
