Introduction

Helm is a package manager for Kubernetes that allows developers and operators to more easily configure and deploy applications on Kubernetes clusters.

Helm packages are called *charts*, and they contain templates of resource definitions that deploy and configure given apps with minimal effort required from the user. With templating, you can manage the chart, its settings and behavior by passing in variable definitions without modifying the actual chart. Customized resource definitions, as well as modifications to already deployed definitions, Helm automatically manages. A deployed chart, with possible customizations, is called a *release*.

In this tutorial, you'll set up Helm 3 and learn how to install, upgrade, roll back, and manage charts and releases. You'll also learn to create and package your own charts, as well as set up chart repositories, which host charts that you can install right away.

Prerequisites

helm illustration for: Prerequisites
  • A Kubernetes cluster with role-based access control (RBAC) enabled. For further information about releases, you can check the Helm releases page.
  • The kubectl command-line tool installed on your local machine, configured to connect to your cluster. You can read more about installing kubectl in the official documentation.

You can test your connectivity with the following command:



  kubectl cluster-info

If you receive no errors, you’re connected to the cluster. If you access multiple clusters with kubectl, be sure to verify that you’ve selected the correct cluster context by running:



  kubectl config get-contexts

The output will list the available configurations:



  [secondary_label Output]

  CURRENT   NAME                    CLUSTER                 AUTHINFO                      NAMESPACE

  *         do-fra1-helm3-example   do-fra1-helm3-example   do-fra1-helm3-example-admin

Here, the asterisk (*) indicates that we are connected to the do-fra1-helm3-example cluster. To switch clusters, run:



  kubectl config use-context <^>context-name<^>

When you are connected to the correct cluster, continue to Step 1 to begin installing Helm.

Step 1 — Installing Helm 3

In this section, you'll install Helm 3 using the officially provided shell script.

Start off by navigating to /tmp, where you'll store the install script by running:



cd /tmp

Download the script with the following command:



curl -fsSL -o get_helm.sh https://raw.githubusercontent.com/helm/helm/master/scripts/get-helm-3

You can examine get_helm.sh in your text editor to ensure it's safe.

Make it executable by setting its permissions to the following:



chmod u+x get_helm.sh

Finally, run it to install Helm 3:



./get_helm.sh

You'll receive output similar to the following:



[secondary_label Output]

Downloading https://get.helm.sh/helm-v3.5.2-linux-amd64.tar.gz

Verifying checksum... Done.

Preparing to install helm into /usr/local/bin

helm installed into /usr/local/bin/helm

You have Helm 3 installed on your machine. You'll now learn about chart repositories and how to use them.

Step 2 — Setting Up Chart Repositories

Helm charts are stored in chart respositories that it is possible for anyone to host. By default, Helm 3 does not come preconfigured with any repository. Previous versions of Helm included a central curated chart repository; however, Helm 3's design deliberately evolved to chart developers managing their own repository, allowing for more freedom and quicker releases. This means that for each chart you wish to use, you'll need to make sure that you add the hosting repository to your Helm installation.

To help you find the right repository, you can use ArtifactHub.io, an open source website managed by the CNCF that catalogues Helm charts and their repositories. It also tracks popular and useful charts that other CNCF projects use, so it differs from the stable repository that previous versions of Helm worked from. For common projects, such as Nginx ingresses or monitoring tools, it's a great source.

You can search for a chart that you'd like to install via the home page. Searching for nginx will show all indexed charts that are related to it.

You'll install the community edition managed by the Kubernetes team. Search for ingress-nginx to find it in your results. Select it to access its page.

Each chart should have a description detailing what it does, coupled with commands for adding its repository to your installation and installing the chart. If it does not, you can still get the necessary commands by pressing on the INSTALL button on the right of the page.

You can click the blue button next to a command to copy it. Do so for the first command, and run it:



helm repo add ingress-nginx https://kubernetes.github.io/ingress-nginx

To add a repository to Helm, you run helm repo add. The parameters it accepts are the name of the repo and its location.

The output will be:



[secondary_label Output]

"ingress-nginx" has been added to your repositories

When you add a new repo, you need to let Helm know what it contains by running:



helm repo update

You'll receive the following output, showing that the update was successful:



[secondary_label Output]

Hang tight while we grab the latest from your chart repositories...

...Successfully got an update from the "ingress-nginx" chart repository

Update Complete. ⎈Happy Helming!⎈

In this step, you've learned about ArtifactHub and what it offers. You've also added a new repo to your Helm installation. In the next step, you'll install a Helm chart.

Step 3 — Installing a Helm Chart

In the previous section, you've added the repo for the ingress-nginx chart. You'll now install it to your cluster.

Each chart has configuration variables that you can set to modify its behavior. These variables are stored in a file called values.yaml that is part of the chart. Unless you've downloaded the chart to your machine, you'll have to run the following command to view it:



helm show values <^>chart_name<^>

To show available variables for ingress-nginx, replace <^>chart_name<^>:



helm show values &lt;^&gt;ingress-nginx/ingress-nginx&lt;^&gt;

The output will be long showing the contents of values.yaml for ingress-nginx.

To install a chart, you can use helm install:



helm install &lt;^&gt;release_name&lt;^&gt; &lt;^&gt;repository&lt;^&gt;/&lt;^&gt;chart_name&lt;^&gt;

A *release* is a deployed instance of the chart, and here you're calling it ingress-nginx.

This command would install the chart to your cluster with the default values of variables. If you wish to modify some of them, you can pass in the new variable values using --set:



helm install ingress-nginx/ingress-nginx &lt;^&gt;--set variable_name=variable_value&lt;^&gt;

You can repeat --set for as many variables as you need. Since we won't be customizing it now, install it as is by running:



helm install ingress-nginx ingress-nginx/ingress-nginx

The output will be similar to the following:



[secondary_label Output]

NAME: &lt;^&gt;ingress-nginx&lt;^&gt;

LAST DEPLOYED: Wed Feb 24 10:12:37 2021

NAMESPACE: default

STATUS: deployed

REVISION: 1

TEST SUITE: None

NOTES:

The ingress-nginx controller has been installed.

It may take a few minutes for the LoadBalancer IP to be available.

You can watch the status by running 'kubectl --namespace default get services -o wide -w ingress-nginx-controller'

...

Note that the NAME corresponds to the name of release you've specified. Helm also lists common information, such as the release status and namespace in which it's deployed. The NOTES section varies between charts, and usually contains quick-start guidance or warns of some common pitfalls when using the chart's resources. Here, it notes that the Load Balancer is being created and that it may take some time to complete.

To check deployed charts, use helm list:



helm list

You'll find that ingress-nginx is the only deployed chart at the moment:



[secondary_label Output]

NAME            NAMESPACE       REVISION        UPDATED                                 STATUS          CHART                   APP VERSION

ingress-nginx   default         1               2021-02-24 10:12:37.281049711 +0000 UTC deployed        ingress-nginx-3.23.0    0.44.0

You can find the services it has in your cluster by running:



kubectl get services

The output will be similar to this:



[secondary_label Output]

NAME                                 TYPE           CLUSTER-IP      EXTERNAL-IP    PORT(S)                      AGE

&lt;^&gt;ingress-nginx-controller&lt;^&gt;             LoadBalancer   10.245.211.81   46.101.68.67   80:30704/TCP,443:30700/TCP   7m19s

&lt;^&gt;ingress-nginx-controller-admission&lt;^&gt;   ClusterIP      10.245.50.17    &lt;none&gt;         443/TCP                      7m19s

kubernetes                           ClusterIP      10.245.0.1      &lt;none&gt;         443/TCP                      83m

Now that you've deployed a release to your cluster, you'll modify its configuration while it's deployed.

Step 4 — Upgrading a Release

Once a release is deployed, you don't have to tear it down and redeploy completely when you need to change its configuration. You can use the helm upgrade command to upgrade the release with a new version of the chart, or to set new settings.

The ingress-nginx chart exposes the controller.replicaCount variable that controls the number of deployed controller pods. By default, it's set to one, which you can verify by listing the available pods:



kubectl get pods

You'll find that there is only one:



[secondary_label Output]

NAME                                        READY   STATUS    RESTARTS   AGE

ingress-nginx-controller-7fc74cf778-kjtst   1/1     Running   0          12m

If you want more to be deployed for redundancy (for instance, three), you can upgrade the release and set the variable to 3 by running:



helm &lt;^&gt;upgrade&lt;^&gt; ingress-nginx ingress-nginx/ingress-nginx &lt;^&gt;--set controller.replicaCount=3 --reuse-values&lt;^&gt;

You also pass in --reuse-values, which instructs Helm to base your changes on top of the deployed release, preserving the previous configuration.

In the output, Helm will bump the revision to signify that the release has been upgraded:



[secondary_label Output]

NAME: ingress-nginx

LAST DEPLOYED: Wed Feb 24 12:07:54 2021

NAMESPACE: default

STATUS: deployed

REVISION: &lt;^&gt;2&lt;^&gt;

TEST SUITE: None

NOTES:

...

You can list the available pods by running:



kubectl get pods

You will find three pods listed, instead of one:



[secondary_label Output]

NAME                                        READY   STATUS    RESTARTS   AGE

ingress-nginx-controller-7fc74cf778-4hk9g   1/1     Running   0          18s

ingress-nginx-controller-7fc74cf778-kjtst   1/1     Running   0          22m

ingress-nginx-controller-7fc74cf778-wz595   1/1     Running   0          18s

Next you'll roll back changes and delete releases altogether.

Step 5 — Rolling Back and Deleting a Release

When you upgrade a release, its revision number is incremented. Internally, Helm stores all revisions of a release, allowing you to return to a previous revision if needed.

To revert the number of pods to just one, you could run helm upgrade again and manually set the number because it's a small change. However, when working with bigger charts with many variables, manually reverting is not feasible and should be automated.

To roll back a release, use helm rollback:



helm rollback &lt;^&gt;release_name&lt;^&gt; &lt;^&gt;release_revision&lt;^&gt;

You can use it to revert the changes you made to ingress-nginx by rolling back to revision 1:



helm rollback &lt;^&gt;ingress-nginx&lt;^&gt; &lt;^&gt;1&lt;^&gt;

You will receive the following output, indicating that the action was successful:



[secondary_label Output]

Rollback was a success! Happy Helming!

You can check the current revision by listing the releases:



helm list

You'll find that the revision is now 3, and not 1:



[secondary_label Output]

NAME            NAMESPACE       REVISION        UPDATED                                 STATUS          CHART                   APP VERSION

ingress-nginx   default         &lt;^&gt;3&lt;^&gt;               2021-02-24 12:43:21.523664768 +0000 UTC deployed        ingress-nginx-3.23.0    0.44.0

Helm regards every change, including rollbacks, as a new revision to a release. You can check that revision 3 is equal to the first one by checking the number of deployed pods by running:



kubectl get pods

You'll find that there is only one:



[secondary_label Output]

NAME                                        READY   STATUS    RESTARTS   AGE

ingress-nginx-controller-7fc74cf778-kjtst   1/1     Running   0          41m

To delete a release and all its revisions, you can use helm delete:



helm delete &lt;^&gt;release_name&lt;^&gt;

Since you won't be needing it anymore, delete ingress-nginx by running the following command:



helm delete &lt;^&gt;ingress-nginx&lt;^&gt;

The output will be:



[secondary_label Output]

release "ingress-nginx" uninstalled

You can list the releases to check that there are none:



helm list

The output table will have no rows:



[secondary_label Output]

NAME    NAMESPACE       REVISION        UPDATED STATUS  CHART   APP VERSION

Now that the release is deleted, you can reuse its name for future deployments.

Step 6 — (Optional) Creating Custom Charts

In this optional step, you'll learn how to create a custom chart, where to put your resource definitions, and how to package it for further distribution.

You'll create a new chart called example-chart. Run the following command to create it:



helm create &lt;^&gt;example-chart&lt;^&gt;

This will create a new directory called example-chart with the following files and structure:



[label example-chart/]

charts/

templates/

├─ tests/

│  ├─ test-connection.yaml

├─ deployment.yaml

├─ hpa.yaml

├─ ingress.yaml

├─ NOTES.txt

├─ service.yaml

├─ serviceaccount.yaml

├─ _helpers.tpl

Chart.yaml

values.yaml

The resource definitions that your chart will install on target clusters are located in the templates directory. The default ones Helm created as a starting point deploy an Nginx ingress controller. Even though their file extension is YAML, they use Go's templating syntax to stay customizable via exposed variables that you can pass in. You can verify by showing the contents of service.yaml by running:



cat example-chart/templates/service.yaml

You'll find that it has templating directives for generating values surrounded by double braces:



[secondary_label Output]

apiVersion: v1

kind: Service

metadata:

  name: {{ include "mychart.fullname" . }}

  labels:

    {{- include "mychart.labels" . | nindent 4 }}

spec:

  type: {{ .Values.service.type }}

  ports:

    - port: {{ .Values.service.port }}

      targetPort: http

      protocol: TCP

      name: http

  selector:

    {{- include "mychart.selectorLabels" . | nindent 4 }}

The referenced variables are exposed to the user and defined in values.yaml. The NOTES text Helm shows after deployment is stored in NOTES.txt, and is also templated. Chart metadata, such as name, version, and version of software being deployed, is specified in Chart.yaml:



[label example-chart/Chart.yaml]

apiVersion: v2

name: mychart

description: A Helm chart for Kubernetes



...

type: application



...

version: 0.1.0



...

appVersion: "1.16.0"

To check what Helm would deploy, you can pass in --dry-run and --debug to helm install pointing at the chart directory:



helm install example-chart --dry-run --debug ./example-chart

The output will be long and contain all the final resource definitions that would get applied to your cluster. While you're working on your chart, you can use helm upgrade to push new versions to Kubernetes.

When it's time to share your finished chart, you can package it for distribution by running:



helm package ./example-chart

The output will be:



[secondary_label Output]

Successfully packaged chart and saved it to: .../example-chart-0.1.0.tgz

The packaged chart can be installed just like the ones from added repositories:



helm install example-chart &lt;^&gt;example-chart-0.1.0.tgz&lt;^&gt;

In this step you've created a custom chart and deployed it. You've also packaged it, and learned about its structure.

Conclusion

You now know how to use Helm to install and upgrade software deployed to your Kubernetes cluster. You've added chart repositories, and learned why they're important and how ArtifactHub can help you find them. You've also created a new custom chart and learned about release revisions and how to roll back if necessary.

For more information on creating custom charts, visit the official guide.
